Direct IP Idis DC-S6261X Operation Manual page 24

Part 1 - Remote Setup
Pattern
Select the Pattern tab and configure pattern settings.
Used to set up a pattern profile for the camera to
follow along.
Displays a list of pattern. The number indicates the
pattern number. Click Setup button to configure the
pattern settings.
• Set: Select a pattern number, enter a name for the
pattern, and then click OK to save the pattern. Move
the camera using directional, zoom, and focus buttons
and then click Stop to save the pattern profile. You can
record up to two minutes of movement.
- , , , , ,
and pan the camera.
- Zoom (In/Out): Zoom in and out.
- Focus (Near/Far): Adjust camera focus to far
or near.
- Speed: Specify the camera's panning and tilting
speed.
• Go To: Select a pattern profile and then click the Run
button to perform the pattern function.
• Edit Name: Used to edit the selected pattern profile.
• Remove: Used to remove the selected pattern profile.
24
, , (Direction): Used to tilt
Tour
Select the Tour tab and configure tour settings.
Used to set up a tour profile of multiple functions in a
designated sequence.
Displays a list of tour. The number indicates the tour
number. Click Setup button to configure the tour
settings.
• Set: Displays a setup window.
- Name: Enter a name for the tour profile.
- No.: Indicates the order of the function in the tour
sequence.
- Function: Select a function to be performed.
- Dwell Time (sec.): Specify how long to perform the
selected function for.
