Ptz - Direct IP Idis DC-S6261X Operation Manual

PTZ

Preset
Select the Preset tab and configure preset settings.
Displays a list of preset. The number indicates the preset
number. Click Setup button to configure the preset.
Use the buttons below to choose a preset position.
- , , , , ,
and pan the camera.
- Zoom (In/Out): Zoom in and out.
- Focus (Near/Far): Adjust camera focus to far
or near.
- Speed: Specify the camera's panning and tilting
speed.
• Set: Choose a preset number and then enter a name.
This saves the current preset under the specified
preset number and name.
• Go To: Select a preset from the list and then click Go
to to move the camera to the selected preset position.
• Edit Name: Used to change the selected preset's
name.
• Remove: Used to remove the selected preset.
(Direction): Used to tilt
, ,
Scan
Select the Scan tab and configure scan settings.
Used to set up a profile for moving the camera
between two points. At least two presets must be
available in order to use the scan feature.
Displays a list of scan. The number indicates the scan
number. Click Setup button to configure the scan
settings.
• Set: Displays a setup window.
- Name: Enter a name for the scan profile.
- Start, Stop: Specify which presets to use as start
and stop points.
- Dwell Time (sec.): Specify how long the camera will
dwell at start and stop positions.
- Speed, Direction: Specify scanning speed and
direction.
• Run: Select a scan profile and then click the Run
button to perform the scan function.
• Edit: Used to edit the selected scan profile.
• Remove: Used to remove the selected scan profile.
Part 1 - Remote Setup
23
