Grizzly H6363 Instruction Sheet

Introduction

The Model H6363 is ideal for production drilling
applications. It features a paddle switch with safe-
ty release, 2,600 RPM free speed and 3⁄8" drilling
capacity. Recommended air pressure is 90 PSI
and average air consumption is 6 CFM. Includes
a 1⁄4" NPT air fitting and chuck key.

Inventory

A. Air Drill ........................................................ 1
B.
⁄ " NPT Air Fitting ....................................... 1
1
4
C. Chuck Key .................................................. 1

Lubricating Your New Air Drill

Lubricate your air drill with pneumatic tool oil. If
you do not have a lubricator installed in your air
line, place 1–2 drops of pneumatic tool oil into the
air fitting daily, as shown in Figure 2.
Damage to your eyes, lungs, and ears could
result from using this drill without proper
protective gear. Always wear safety glasses,
a respirator, and hearing protection while
drilling.
Need Help?
If you need help with your new air drill, call our
service department at: (570) 546-9663.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © NOVEMBER, 2004 BY GRIZZLY INDUSTRIAL, INC.
#TR6761 PRINTED IN CHINA
⁄ " STRAIGHT AIR DRILL
3
8
MODEL H6363
INSTRUCTION SHEET
Figure 1.
Lubricating the Model H6363.
Figure 2.
Model H6363.
