Grizzly H6364 Instruction Sheet

Introduction
For high speed drilling applications, this
Straight Air Drill delivers a free speed of 18,000
RPM. The in-line design also improves balance
and control. Recommended air pressure is 90 PSI
and average air consumption is 6 CFM. Includes
a ⁄ " NPT quick connect fitting and chuck key.
1
4
Inventory
A. Air Drill ........................................................ 1
B.
⁄ " NPT Quick Connect Fitting (male) ........ 1
1
4
C. Chuck Key .................................................. 1
Lubricating Your New Air Drill
Lubricate your air drill with pneumatic tool oil. If
you do not have a lubricator installed in your air
line, place one drop of pneumatic tool oil into the
air fitting daily, as shown in Figure 2.
Damage to your eyes, lungs, and ears could
result from using this drill without proper
protective gear. Always wear safety glasses,
a respirator, and hearing protection while
drilling.
Need Help?
If you need help with your new air drill, call our
service department at: (570) 546-9663.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © NOVEMBER, 2004 BY GRIZZLY INDUSTRIAL, INC.
#TR6754 PRINTED IN CHINA
⁄ " STRAIGHT AIR DRILL
3
8
INSTRUCTION SHEET
⁄ "
3
8
Figure 2.
18,000 RPM
MODEL H6364
Model H6364.
Figure 1.
Lubricating the Model H6364.
