Grizzly H6362 Parts List

��
��
��
��
Ref # Part # Description
1 PH6362001 HOUSING
2 PH6362002 SPRING PIN
3 PH6362003 EXHAUST DEFLECTOR
4 PH6362004 O-RING
5 PH6362005 AIR FITTING CONNECTOR
6 PH6362006 SPECIAL SCREW
7 PH6362007 VALVE STEM
8 PH6362008 O-RING
9 PH6362009 REVERSE BUSHING
10 PH6362010 O-RING
11 PH6362011 REVERSE LEVER
12 PH6362012 SPRING
13 PH6362013 TRIGGER
14 PSS81M SET SCREW M3-.5 X 5
15 PH6362015 MOTOR GASKET
16 PH6362016 BEARING
17 PH6362017 END PLATE
H6362 Parts Breakdown and List
��
��
��
�� ��
��
��
��
��
��
��
��
��
��
��
��
��
��
��
Ref #
18 PH6362018
19 PH6362019
20 PH6362020
21 PH6362021
22 PH6362022
23 PH6362023
24 PH6362024
25 PH6362025
26 PH6362026
27 PH6362027
28 PH6362028
29 PH6362029
30 PH6362030
31 PH6362031
32 PH6362032
33 PH6362033
�� ��
��
�
�
�
Part # Description
CYLINDER
ROTOR BLADE
ROTOR
PIN
SPACER
INTERNAL GEAR
PLANET GEAR
PIN
WORK SPINDLE
BEARING
CLAMP NUT
GASKET
DRILL CHUCK
CHUCK SCREW
1/4" NPT MALE AIR FITTING
CHUCK KEY
�
�
�
�
�
�
��
