Grizzly H6194 Instruction Sheet

EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!

Introduction

Heavy-duty industrial air drill features paddle
switch for easy control, a
air exhaust and rugged aluminum body. It has a
22,000 RPM free speed with 4 CFM average air
consumption.
A. Industrial Air Drill ........................................ 1
B. ⁄ " Jacobs Chuck ...................................... 1
3 ®
8
C. Chuck Key .................................................. 1
D. Wrench ....................................................... 1

Operation

Screw the chuck on the arbor and tighten with the
wrench provided. Add a
connect to your regulated compressed air supply.
Do not exceed 90 PSI!
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
INJURY HAZARD!
EXPLOSION HAZARD!
Never exceed 90 PSI!
⁄ " Jacobs chuck, rear
3 ®
8
⁄ " MNPT air fitting and
1
4
COPYRIGHT © APRIL, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8030 PRINTED IN CHINA
MODEL H6194
⁄ " INDUSTRIAL AIR
3
8
DRILL
INSTRUCTION SHEET
Figure 1. Model H6194.
This industrial air drill MUST have 3-4 drops of oil
directly dropped into the air fitting before each use
as shown in Figure 2.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
