Up to 5 Kfactors can be pre-programmed for quick use.

When Flow is set as the Primary measurement in the Display
Setup menu, the Kfactor will also be displayed.
When measuring Flow as the Primary measurement, the parameters
can be quickly changed by pressing the  or  key while on the
main measurement screen. Make adjustments with the  or 
arrow keys and press
menu to choose a different pre-programmed flow value.

ACTUAL/STANDARD SETUP

Choose Actual/Standard measurements and parameters in the
Act/Std Setup menu. Within this menu, the user can also select
Standard Temperature, Standard Pressure and a source for the
actual temperature. The actual barometric pressure must be entered
to convert air velocity and volume measurements to actual conditions.
The Entered Temp range is from -40 to 1832°F (-40 to 1000°C).

DATA LOGGING

Measurements

Measurements to be logged are independent of measurements
on the display, and must therefore be selected under DATA
LOGGING  Measurements.




Log Mode/Log Settings

You can set Log Mode to Manual, Auto-save or Cont-key.



Operation
uality Products Online at:
When set to ON, measurement will be logged to memory.
When set to DISPLAY, measurement will be logged to memory
if it is visible on the main running screen.
When set to OFF, measurement will not be logged to memory.
In Cont-key mode, the user starts taking readings and logging
by pressing the  key. The instrument will continue taking
measurements until the  key is pressed again.
Auto-save and Cont-Key modes have the following additional
Mode
Auto-save
Cont-key
Pressing the  keys simultaneously will lock the keypad to
prevent unauthorized adjustments to the instruments. To
unlock the keypad, press the  keys simultaneously.
