- Page 1 SW12 CUTTING UNIT USE MANUAL...
- Page 2 All the parts of the devices have been planned and produced to guarantee an optimum performance. In order to keep the high quality level and the long reliabilty of the Rasor ® products, it is recommended to use only original spare parts and to contact the head...
-
Page 3: General Safety Rules
1. GENERAL SAFETY RULES This manual is an integral part of cutting unit SW12SSX and must be carefully read before using it since it gives important indications with regards to its safe installation, use and maintenance. Keep it with care. - Page 4 Moreover, they cannot work in case of rain. In case of damage or malfunction, cutting unit SW12SSX must not be used until the Customer Care Technical Service has repaired them.
-
Page 5: Transport And Packaging
In such a case, the operator is the only person responsible. Class II double insulation Model Serial number SW12SSX 220 230 50 60 Electric data Year of production R EAD... -
Page 6: Product Description
4. PRODUCT DESCRIPTION The fixture described in this manual is a cutting unit model SW12SSX which can be assembled on automatic machines (e.g. spreaders, computerized cutting) by means of proper holes located in the motor support. SW12SSX can operate continuously and it can cut at various widths by means of multiple installation. -
Page 7: Technical Features
This technical data is only indicative and may be subject to change without notice. 6. NOISE LEVEL The maximum acoustic pressure level emitted by cutting unit SW12SSX is about 60 dB (A). Noise tests have been carried out in compliance with Standard ISO 11202 (1995). The device noise levels, measured at different distances (without any sound wave filtering system), vary in the extent of few db (A). -
Page 8: Use Warnings
® 9. ELECTRIC CONNECTION Firstly make sure that the lines and electric systems of the machine, on which the SW12SSX will be installed, are able to supply the cutting unit with power correctly, in compliance with the safety rules (for the feature required see par. 5). -
Page 9: Residual Risks
WARNING Never use the two bolts which fix the motor to the cutting part to fasten cutting unit SW12SSX. This operation may cause the motor shaft to break. In this case, warranty is not valid. -
Page 10: Blade Sharpening
To carry out this operation, remove protective plug “A” located on the motor support of the cutting unit and fill it with lubricating grease Rasor. Screw plug “A” again few turns. Screw plug “A” some turns every 3-4 working hours (see picture 11). -
Page 11: Blade Replacement
5) Replace the worn blade with the new one “2”, being careful to center the blade on the shaft, in the correct position, and remember to assemble it, so that the Rasor writing can be seen by the operator. 6) Assemble all the components again and carry out... -
Page 12: Troubleshooting
16. TROUBLESHOOTING PROBLEM SOLUTION Check that the blade and the counterblade are in contact Check the kind of fabric Sharpen the blade Check the fabric thickness The fabric is not cut or it gets stuck between the blade and the counterblade Check the compatibility between blade and fabric Make sure that the motor turns correctly Reduce the speed of travel... - Page 13 ® dal 1946...
-
Page 14: Warranty
If in-warranty goods need to be repaired, the customer must always send the complete machine to Rasor . Single units will not be repaired under warranty. ®... - Page 15 RASOR ELETTROMECCANICA SRL Via Vincenzo Caldesi 6 20161 Milan ∙ Italy ph. +39 02 66 22 12 31 fax +39 02 66 22 12 93 info@rasor-cutters.com www.rasor-cutters.com FOLLOW US:...
