VENTED GAS LOG APPLIANCE
OWNER'S OPERATION AND
INSTALLATION MANUAL
DANGER
•
•
•
WARNING: No not store gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be stored in
the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Read the installation, operating and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE
WARNING
This appliance can pro-
duce carbon monoxide
which has no odor.
Using it in an enclosed
space can kill you.
Never use this appli-
ance in an enclosed
space such as a camp-
er, tent, car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
For more information, visit www.fmiproducts.com
REMOTE-READY LOG SET AND BURNER
SYSTEM MODELS
MF42ONR, MF42OPR, MF48ONR, MF48OPR,
VTDGT24NR, VTDGT24PR, VTDGT30NR,
VTDGT30PR, VTDGT36NR, VTDGT36PR
MF42 MODELS MAY BE USED WITH LMF36-SC AND
LMF42-SC LOGS ONLY
PFS
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
®
US
Advertisement
Table of Contents
Related Manuals for FMI VTDGT24NR
Summary of Contents for FMI VTDGT24NR
- Page 1 REMOTE-READY LOG SET AND BURNER SYSTEM MODELS MF42ONR, MF42OPR, MF48ONR, MF48OPR, VTDGT24NR, VTDGT24PR, VTDGT30NR, VENTED GAS LOG APPLIANCE VTDGT30PR, VTDGT36NR, VTDGT36PR OWNER’S OPERATION AND MF42 MODELS MAY BE USED WITH LMF36-SC AND INSTALLATION MANUAL LMF42-SC LOGS ONLY MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY ®...
-
