OWNER'S OPERATION AND
INSTALLATION MANUAL
DANGER
• This appliance can pro-
• Using it in an enclosed
• Never use this appliance
WARNING: Improper installation, adjust-
ment, alteration, service or maintenance
can cause injury or property damage. Read
the installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
WARNING: For Outdoor Use Only.
CARBON MONOXIDE
WARNING
duce carbon monoxide
which has no odor.
space can kill you.
in an enclosed space
such as a camper, tent, car
or home.
For more information, visit www.fmiproducts.com
FIRE RING MODELS
MM2FR, MM2FRL, MM3FR AND MM3FRL
NATURAL GAS BURNER MODELS:
MMFRBNB AND MMFRBNS
PROPANE/LP GAS BURNER
MODELS:
MMFRBPB AND MMFRBPS
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
WARNING: Do not store gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
An LP-cylinder not connected for use shall not
be stored in the vicinity of this or any other
appliance.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FMI MM2FR
Summary of Contents for FMI MM2FR
- Page 1 FIRE RING MODELS MM2FR, MM2FRL, MM3FR AND MM3FRL NATURAL GAS BURNER MODELS: MMFRBNB AND MMFRBNS PROPANE/LP GAS BURNER MODELS: MMFRBPB AND MMFRBPS OWNER’S OPERATION AND INSTALLATION MANUAL CARBON MONOXIDE DANGER DANGER WARNING IF YOU SMELL GAS: • This appliance can pro- 1.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..............2 Cleaning and Maintenance ........14 Local Codes............3 Troubleshooting ..........15 Unpacking............3 Parts ..............18 Specification ............4 Service Hints .............21 Installation ............5 Technical Service..........21 Operation ............12 Replacement Parts ..........21 Inspecting Burners..........13 Warranty ..........Back Cover SAFETY Solid fuels shall not be burned in this Natural and Propane/LP gases are odorless. -
Page 3: Local Codes
American National Standards Institute, Inc. blocks for shipment. 1430 Broadway New York, NY 10018 3. Check for any shipping damage. If appliance is damaged call FMI PRODUCTS, LLC at National Fire Protection Association, Inc. 1-866-328-4537 for replacement parts before Batterymarch Park returning to dealer. -
Page 4: Specification
SPECIFICATIONS 50.625” 29.125” MM2FR: 17.125” MM3FR: 24.250” 47.875” Figure 1 - MODELS MM2FR, MM2FRL, MM3FR AND MM3FRL MMFRBNB, MMFRBNS MMFRBPB, MMFRBPS • Rating: 96,000 Btu/hr • Rating: 95,000 Btu/hr • Gas Type: Natural Gas Only • Gas Type: Propane/LP Gas Only •... -
Page 5: Installation
INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified service person must WARNING: This appliance requires a 1/2" install appliance. Follow all local codes. NPT (National Pipe Thread) inlet connection NOTICE: State or local codes may only allow to the pressure regulator. operation of this appliance in a vented con- figuration. - Page 6 INSTALLATION Continued Propane/LP External Equipment Supply Tank Regulator Shutoff Valve with Vent With 1/8" NPT Pointing Tap* Down PROPANE/LP From External Regulator Approved Flexible (11" W.C.** Gas Hose (no to 14" W.C. longer than 36" if required by local Pressure) codes) NATURAL 3"...
- Page 7 INSTALLATION Continued CHECKING GAS CONNECTIONS Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa) WARNING: Test all gas piping and connec- 1. Close equipment shutoff valve (see Figure 4). tions, internal and external to unit, for leaks 2. Pressurize supply piping system by either open- after installing or servicing.
- Page 8 INSTALLATION Continued GAS LINE PLANNING 1. Locate a flat even surface to build your fire ring. See Specifications page 4 for sizing and The supply line will need to run vertical through the Minimum Clearances page 5 when selecting a heat shield in the center of the fire ring up to where location.
- Page 9 Figure 10 - Heat Shield Retaining Brackets (MM2FR Shown) 6. Place Block cover over open block in the first layer for the MM2FR or the second layer for the MM3FR as shown in Figure 11. Figure 8 - Staggered Blocks...
- Page 10 Figure 13. 11. Place lava retaining bracket as shown in Figure Heat Shield Controls Figure 12 - Installing Heat Sheild (MM2FR Shown) Figure 14 - Burner System (MM2FR Shown) Burner Retaining Brackets Lava Retaining Bracket Figure 15 - Lava Retaining Bracket...
- Page 11 Lastly place the largest rocks in the center making a teepee formation. Figure 16 - Concrete Cap (MM2FR Shown) Figure 17 - Access Door (MM2FR Shown) www.fmiproducts.com...
-
Page 12: Operation
OPERATION 5. Turn control knob counterclockwise to the FOR YOUR SAFETY PILOT position and press in. Keep control knob READ BEFORE LIGHTING pressed in for five (5) seconds. WARNING: Keep flue open when operating Note: You may be running this fire ring for the unit. -
Page 13: Inspecting Burners
OPERATION Continued TO TURN OFF GAS CURING TO APPLIANCE During 2-3 hour appliance break-in period, 1. Turn control knob clockwise to the PILOT you may detect an odor from the appliance as position. various paints and compounds used in manu- 2. -
Page 14: Cleaning And Maintenance
CLEANING AND MAINTENANCE Clean pilot assembly also. Additional cleaning may WARNING: Turn off appliance and let cool be needed for proper pilot operation based on use/ before cleaning. lack of use. A yellow tip on the pilot flame may indicate dust and dirt in the pilot assembly. There CAUTION: You must keep control areas, is a small pilot air inlet hole about from where the burners and circulating air passageways of ap-... -
Page 15: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ignitor button is pressed, 1. - Page 16 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Pilot lights but flame goes out 1. Control knob not fully 1. Press in control knob fully when control knob is released pressed in 2. Control knob not pressed in 2. After pilot lights, keep control long enough knob pressed in 30 seconds 3.
- Page 17 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •...
-
Page 18: Parts
PARTS BURNER MODELS MMFRBNB, MMFRBPB, MMFRBNS, MMFRBPS www.fmiproducts.com 125883-01C... - Page 19 PARTS This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. NO. PART NO. DESCRIPTION QTY. 125889-01 Burner - Black • • 125889-02 Burner - Stainless •...
- Page 20 This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. BLOCK COVER 125957-03 MM2FR & MM3FR - QUANITY 1 CONCRETE CAP 125868-01 MM2FRL & MM3FRL - QUANITY 1 MM2FR &...
-
Page 21: Service Hints
TECHNICAL SERVICE • your address You may have further questions about installation, • model and serial numbers of your appliance operation or troubleshooting. If so, contact FMI • how appliance was malfunctioning PRODUCTS, LLC at 1-866-328-4537. When call- • purchase date... - Page 22 NOTES ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...
- Page 23 NOTES ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...
-
Page 24: Warranty
FMI PRODUCTS, LLC makes no other warranties regarding this product. FMI PRODUCTS, LLC’s liability is limited to the purchase price of the product, and FMI PRODUCTS, LLC shall not be li- able for any other damages whatsoever under any circumstances including indirect, incidental, or consequential damages.
