WPA-PSK/WPA2-PSK Passphrase - You can enter a WPA or WPA2 passphrase between 8 and
63 characters long.
Group Key Update Period - Specify the group key update interval in seconds. The value can be
either 0 seconds or from 30 seconds and up, 1-29 seconds are not usable figures. Enter 0 to
disable the update.
Radius Server IP - Enter the IP address of the Radius Server
Radius Port - Enter the port number that the radius service used.
Radius Password - Enter the password for the Radius Server.
Be sure to click the Save button to save your settings on this page.
Note: The router will reboot automatically after you click save.

4.5.2 MAC Filtering

The Wireless MAC Filtering for wireless networks are set on this page, Figure 4-18:
The Wireless MAC Address Filtering feature allows you to control wireless stations accessing the router,
MR5-WR542G
Figure 4-17 WPA/WPA2
Figure 4-18 Wireless MAC address Filtering
