Crystal Image Technologies KVM-1201D User Manual page 5

Before Installation
■
It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■
Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
Unpacking
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Installation for standalone KVM
A
UM-CV-DVIKVM-Q212V3
Screw A: 2 pcs
M3.2 x 4.5 mm
■
Install each bracket using screws
B provided shown in Figure 1.
■
Fix the KVM into the rack
Figure 1.
Screw B: 8 pcs
M4 x 10 mm
