4. SPECIFICATIONS

Models
Input Voltage Range
No Load Input Current at 230VAC
Full Load Input Current at 230VAC
AC input Frequency
Efficiency
Power Factor
Constant Voltage and Current Range Selection:
0.5-36V / 0-5A
Constant Voltage Characteristics:
Adjust Resolution
Load Regulation (10 – 90%)
Line Regulation (±10%)
Ripple & Noise (peak-peak)
Constant Current Characteristics:
Adjust Resolution
Load Regulation (10 – 90%)
Line Regulation (±10%)
Voltmeter & Ammeter Accuracy
User adjustable upper current & voltage limit
Number of preset recalls of frequent use V&I setting
Remote Sensing
Ramp Step Irregular Waveform functions
Number of Voltage Level Setting
Settable Output Time Period of each Voltage Level
Remote Programmable / Control by PC
Protection
Standard Communication Port
Optional Interface (not included)
Additional Function
Cooling Method
Dimensions (WxHxD)
Weight
◘ All values are based on the Standard ambient Temperature 25°C and Pressure 0.1Mpa.
◘ SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
MP780083
100 – 240VAC
≤150mA
≤500mA
50 – 60 Hz~
≥78%
≥0.9
Auto range with maximum output power 80W (V x A ≤80W)
10mV
≤30mV
≤4mV
≤35mA
10mA
≤10mA
≤10mA
±(0.5% +5counts)
Yes
3
Yes
10
0 to 1200 seconds
Output ON/OFF, Voltage & Current Control, Selection of Voltage
and Current Preset, Programmable of cyclic output and data
logging of output, Upper Voltage & Current Limit control.
Tracking Over Voltage Protection, Current Limiting Protection,
Short Circuit, Overload, Over Temperature, Upper Voltage Limit,
Upper Current Limit.
USB 2.0
Ethernet, Factory or User install
Master/Slave Control
Natural Convection
53.5x127x330mm 2x5x13 inch
Approx. 1.9kgs 4.2lbs
P.5
