COM setting

Set up the COM port inside the computer according to the following list:
• Baud rate: 9600,19200,38400,57600,115200
• Parity bit: None
• Data bit:8
• Stop bit:1
• Data pow control: None

Functionality Check

• Run this query command via the terminal application, such as MTTTY (Multi-threaded TTY).
• This should return the idenitiycation information: Manufacturer, model name, serial number,
MP711005 VX.X SN: XXXXXXXxxx
Entering the Remote Control Mode
• Connect the USB.
• The power supply will automatically connect. After a normal connection, there will be a tweet from the power supply itself.
• The panel keys are locked, so the power supply can only rely on the remote control.
Exiting from the Remote Control Mode
• Close the remote control software.
• Disconnect the USB from the back.
• Disconnect the USB from the back.
• The power supply automatically comes in the panel control mode.

SPECIFICATIONS

Note: The specifications in the table below have all been tested in temperature ranging from 25°C down to -5°C, and after
being warmed up for 20 minutes.
Model
Voltage Range
Current Range
Load Regulation
Voltage Current
Important Notice : This data sheet and its contents (the "Information") belong to the members of the AVNET group of companies (the "Group") or are licensed to it. No licence is granted for
the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change
without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness,
any error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make
any assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or
where the Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its
negligence. Multicomp Pro is the registered trademark of Premier Farnell Limited 2019.
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
MP711005 / MP711006 / MP711007 / MP711008 / MP711009
0-30V
0-5A
≤0.01%+2mV
≤0.1%+5mMA
