- Page 1 OMEGA...
- Page 2 European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Safety Information
SAFETY INFORMATION The following safety information must be observed to insure maximum personal safety during the operation at this meter: 1. Do not use the meter if the meter or test leads look damaged, or if you suspect that the meter is not operating properly. 2. -
Page 4: Specifications
SPECIFICATIONS Display: 3½ digit liquid crystal display (LCD) with a maximum reading of 1999. Polarity: Automatic, positive implied, negative polarity indication. Overrange: (OL) or (-OL) is displayed. Zero: Automatic. Low battery indication: the " " is displayed when the battery voltage drops below the operating level. - Page 5 DC VOLTS Ranges: 200mV,2V,20V,200V,600V Resolution: 100µV Accuracy: ±(0.35%rdg + 1dgt) Input impedance: 10MW Overload protection: 500VDC or AC rms on 200mV range 600VDC or AC rms on all other ranges AC VOLTS (50Hz - 500Hz) Ranges: 200V,600V Resolution: 100mV Accuracy: ±(1.5%rdg + 4dgts) Input impedance: 10MW Overload protection: 500VDC or AC rms on 200mV range 600VDC or AC rms on all other ranges...
- Page 6 RESISTANCE Ranges: 200W ,2KW ,20KW ,200KW ,2MW ,20MW Accuracy: ±(0.4%rdg + 3dgts) on 200W range ±(0.4%rdg + 1dgt) on 2KW to 2MW ranges ±(3.0%rdg + 3dgts) on 20MW range Open circuit volts: 0.3Vdc (3.0Vdc on 200W range) Overload protection: 500VDC or AC rms CONTINUITY Audible indication: less than 100W Overload protection: 500VDC or AC rms...
- Page 7 FREQUENCY (Autoranging) Ranges: 2KHz,20KHz,200KHz,2000KHz,15MHz Accuracy: ±(0.1%rdg + 1dgt) Sensitivity: 1.0Vrms (TTL level) Overload protection: 500VDC or AC rms Effect Reading: 10 - 1999 TRANSISTOR hFE Ranges: 0 - 1000 Base current: 10µAdc approx. (Vce=3.0Vdc) TEMPERATURE Ranges: -4°F to 1400°F Resolution: 1°F Accuracy: ±(2.0%rdg + 6dgts) on -4°F to 900°F ±(3.0%rdg + 4dgts) on 900°F to 1400°F...
-
Page 8: Operation
OPERATION Before taking any measurements, read the Safety Information Section. Always examine the instrument for damage, contamination (excessive dirt, grease, etc.) and defects. Examine the test leads for cracked or frayed insulation. If any abnormal conditions exist do not attempt to make any measurements. - Page 9 Current Measurements 1. Set the Function/Range switch to the desired current range. 2. For current measurements less than 200mA, connect the red test lead to the µAmA jack and the black test lead to the COM jack. 3. For current measurements over 200mA or greater, connect the red test lead to the 10A jack and the black test lead to the COM jack.
- Page 10 Diode Tests 1. Connect the red test lead to the "VW " jack and the black test lead to the "COM" jack. 2. Set the Function/Range switch to the " " position. 3. Turn off power to the circuit under test. 4.
- Page 11 Transistor Gain Measurements 1. Set the Function/Range switch to the desired hFE range (PNP or NPN type transistor). 2. Never apply an external voltage to the hFE sockets. Damage to the meter may result. 3. Plug the transistor directly into the hFE socket. The sockets are labeled E, B and C for emitter, base, and collector.
-
Page 12: Maintenance
MAINTENANCE WARNING Remove test leads before changing battery or fuse or performing any servicing. Battery Replacement Power is supplied by a 9 volt "transistor" battery. (NEDA 1604 IEC 6F22). The " " appears on the LCD display when replacement is needed. To replace the battery, remove the two screws from the back of the meter and lift off the battery case. - Page 13 CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a "Basic Component" under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any...
-
Page 14: Data Acquisition
Where Do I Find Everything I Need for Process Measurement and Control? OMEGA...Of Course! TEMPERATURE DATA ACQUISITION PRESSURE/STRAIN AND FORCE HEATERS FLOW/LEVEL ENVIRONMENTAL MONITORING AND CONTROL pH/CONDUCTIVITY M-2850/0799...
