A64 Dome Camera
Quick Start Guide
1

Advertisement

Table of Contents
loading

Related Manuals for advidia A64

Summary of Contents for advidia A64

  • Page 1 A64 Dome Camera Quick Start Guide...
  • Page 2 Network Dome Camera · Quick Start Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the following models. Model This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
  • Page 3 Network Dome Camera · Quick Start Guide FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Network Dome Camera · Quick Start Guide municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 5 Network Dome Camera · Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 6 Network Dome Camera · Quick Start Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket.
  • Page 7 Network Dome Camera · Quick Start Guide damp locations, and do not expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ●...

  • Page 8: Table Of Contents

    Network Dome Camera · Quick Start Guide Table of Contents 1 Appearance Description ..............8 2 Installation ..................10 2.1 Ceiling Mounting ............11 2.2 Wall Mounting .............. 15 2.3 3-axis Adjustment and Lens Adjustment ....... 17 2.3.1 3-axis Adjustment ..........17 2.3.2 Lens Adjustment..........

  • Page 9: Appearance Description

    Network Dome Camera · Quick Start Guide 1 Appearance Description The overview of the network dome camera is shown below. Figure 1-1 Overview 4 5 6 7 8 9 Figure 1-2 Detailed Components Table 1-1 Description...
  • Page 10 Network Dome Camera · Quick Start Guide Description Description Black Liner Audio Out Bubble Reset Button Power Interface CVBS Interface Alarm Output A SD Card Slot Alarm Output B Mounting Base Grounding Lens Alarm Input Network Interface Audio In  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 11: Installation

    Network Dome Camera · Quick Start Guide 2 Installation Before you start: Make sure the device in the package is in good condition and all  the assembly parts are included. Make sure all the related equipment is power-off during the ...

  • Page 12: Ceiling Mounting

    Network Dome Camera · Quick Start Guide ● The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to camera body so that the foam ring and the dome cover are attached seamlessly.
  • Page 13 Network Dome Camera · Quick Start Guide Figure 2-2 Installation of the Screws 3. Use a hexagonal screwdriver to loosen the lock screw on the bubble, and remove the black liner. 4. Route the cables from the cable hole, and connect the corresponding cables.
  • Page 14 Network Dome Camera · Quick Start Guide Side Outlet Figure 2-3 Route the Cables via Side Outlet 5. Align the screws holes on the camera to the inserted screw, and rotate the camera to hook the camera to the screws. 6.
  • Page 15 Network Dome Camera · Quick Start Guide Figure 2-4 Install the Black Liner and Bubble 8. Tighten the lock screw on the bubble. Figure 2-5 Tighten the Lock Screw...

  • Page 16: Wall Mounting

    Network Dome Camera · Quick Start Guide 2.2 Wall Mounting You need to purchase a wall bracket separately if wall mounting is selected. 1. Fix the wall bracket to the wall with the screws. Please insert the expansion screws first if the camera is mounted to the cement wall, and you can use the self-tapping screws directly if camera is mounted to the wooden wall.
  • Page 17 Network Dome Camera · Quick Start Guide Screw Figure 2-7 Install the Rubber Ring and Screws 5. Align the screws holes on the camera to the installed screws, and rotate the camera to hook to the camera to the screws. 6.

  • Page 18: 3-Axis Adjustment And Lens Adjustment

    Network Dome Camera · Quick Start Guide 7. Tighten the lock screw on the bubble. Lock Screw Figure 2-9 Tighten the Lock Screw 2.3 3-axis Adjustment and Lens Adjustment 2.3.1 3-axis Adjustment This series of camera supports 3-axis adjustment, and you can adjust the camera to the desired surveillance angle after the black liner is installed.

  • Page 19: Lens Adjustment

    Network Dome Camera · Quick Start Guide 0°~80° 0°~355° 0°~355° Figure 2-10 3-axis Adjustment 2.3.2 Lens Adjustment Please refer to the chapter 3 and chapter 4 for details to login to the camera. Figure 2-11 Zoom/Focus Adjustment Via Live View Connect the camera to a debug monitor so as to get the live view, and adjust the zoom lever (T~W) to adjust the zoom, and adjust the focus lever (F~N) to adjust the focus till you get a clear view.
  • Page 20 Network Dome Camera · Quick Start Guide Figure 2-12 Lens Adjustment...

  • Page 21: Setting The Network Camera Over The Lan

    To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the Advidia Camera Finder Utility to search and change the IP of network camera.
  • Page 22 This search may take 30 seconds or more depending on network size. After searching it will show total number and information of the Advidia cameras found on the network. Device information including the device type, IP address, port number, gateway, etc.
  • Page 23 Network Dome Camera · Quick Start Guide Click the refresh icon to refresh the online device list manually. The newly discovered devices will be added to the list. Note: You can click on each column heading to order the information. ...
  • Page 24 Network Dome Camera · Quick Start Guide Login Manager Figure 3-4 Launch Edit Table Figure 3-5...
  • Page 25 Network Dome Camera · Quick Start Guide Edit Table Figure 3-6 5) Enter the desired IP address (or range if changing the IP address of more than one device) of the network camera in the address field of the edit table and click Apply Network Changes. You can also select “Dynamic IP”...

  • Page 26: Accessing Via Web Browser

    Network Dome Camera · Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari...
  • Page 27 Network Dome Camera · Quick Start Guide Login Interface Figure 4-1 5) Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
  • Page 28 Network Dome Camera · Quick Start Guide Download Plug-in Figure 4-2 Install Plug-in Figure 4-3...
  • Page 29 Network Dome Camera · Quick Start Guide Install Plug-in Figure 4-4 6) Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the camera’s user man...
