- Page 1 EZTK90BL Extractor Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
-
Page 2: Table Of Contents
Contents: Important Important information Using your extractor Care and maintenance Removing the grease filter(s) Changing/fitting the charcoal filter(s) Changing the light 10 - 16 Installation Installation preparation - height Ducting and ventilation Mains electricity connection Electrical information Troubleshooting Energy Efficiency Information... -
Page 3: Important
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model... -
Page 4: Important Information
and requirements of EU Directive 2014/30/EU (EMC). IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. - Page 5 • This extractor has been designed to be used in a room with a volume of less than 36m3. • Steam cleaners must not be used when cleaning this appliance. • The performance of your extractor will vary depending on a number of factors.
-
Page 6: Using Your Extractor
Using your extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. Fig. 1 Control Panel A - Power off button B - Speed level buttons C - Light button To switch the extractor light on or off... -
Page 7: Care And Maintenance
Care and maintenance IMPORTANT: DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY SUPPLY. Cleaning You should use a non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could damage the control panel markings. - Page 8 Removing and cleaning the grease filter(s) - Fig. 2 The grease filters should be kept clean to minimise the risk of fire. At least once a month you should remove and clean the grease filters with hot soapy water. You can also wash the grease filters in a dishwasher (see note on page 9), ensuring that you place it in an upright position to prevent damage from other items in the dishwasher.
- Page 9 Please note: Cleaning the grease filters in the dishwasher may lead to discolouration. This is normal and does not constitute a fault with the appliance. Changing the charcoal filter (re-circulating only) - Fig. 3 To ensure best performance of your extractor, you should replace the charcoal filters every four to six months, depending on use.
-
Page 10: Changing The Light
These are not user-replaceable in the unlikely event of a failure. If the lights on your extractor should fail, please contact CDA Customer Care. Contact details are below, on page 18 and on the rear cover of this manual. -
Page 11: Installation Preparation - Height
Installation preparation - height When the extractor is to be installed above an electric hob, the minimum distance between the hob and extractor must exceed 650mm. When the extractor is to be installed above a gas hob, the minimum distance between the hob and extractor must exceed 650mm. If the instructions provided with your gas hob state that the required distance between the hob and extractor must be greater than 700mm, then that is the distance that should be observed;... - Page 12 Fig. 4 Fig. 5 Fig. 5 Minimum distance from CDA Electric Hob = 650mm Minimum distance from CDA Gas Hob = 650mm Fig. 6 Taking into account the extractor dimensions, and the advice regard- ing installation height as per page 11, mark where the installation cage will be.
-
Page 13: Ducting And Ventilation
Ducting and ventilation For best performance and lowest noise output, we recommend the use of 150mm ducting. You can also use smaller diameter ducting but this will reduce performance. In general, the less ducting you use (i.e. distance and bends) the more efficient your extractor will be. Before cutting/drilling through any surfaces, ensure that adequate measures have been... - Page 14 Fig. 9 Fig. 10 Fig. 11 Fig. 12 • Taking care not to damage them, slide the chimney sections over the installation cage (Fig. 14). Slide both sections up to the top of the installation cage. Support the chimney sections and fit the four silver machine screws, pictured:...
- Page 15 Fig. 11 Fig. 13 Fig. 14 The holes that these screw into are approximately half way up the installation cage. (Fig. 15). These will support the chimney sections whilst you fit the extractor body. • Attach the extractor body to the installation cage at the desired height (Fig.
- Page 16 Fig. 15 Fig. 16 Fig. 17 Fig. 18 • Remove the grease filters and connect the 10 pin connector to the 10 pin lead in the extractor body. Refit the box to house the two. • Switch on the mains supply to the extractor and double check that everything works.
-
Page 17: Mains Electricity Connection
Mains Electricity Connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A 3A FUSE. DOUBLE POLE We recommend that the appliance is SWITCHED FUSED SPUR OUTLET connected by a qualified electrician,... -
Page 18: Electrical Information
If the lights still do not work, contact CDA Customer Care: Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY T: 01949 862 012 F: 01949 862 003 E: customer.care@cda.eu... - Page 19 NOTES: E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 20 T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu Copyright © CDA 2017...
