Summary of Contents for CDA EVPC91
- Page 1 EVPC91 Corner Extractor Installation, use and maintenance www.cda.eu...
-
Page 2: Table Of Contents
Contents: Important Important information Using your extractor Timer function Clean air function Care and maintenance Removing the grease filter Changing/fitting the charcoal filter(s) Changing the light 11 - 17 Installation Installation preparation - height Mounting the extractor Ducting and ventilation Mains electricity connection Electrical information 19 - 20... -
Page 3: Important
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model... -
Page 4: Important Information
and requirements of EU Directive 2014/30/EU (EMC). IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. - Page 5 • This extractor has been designed to be used in a room with a volume of less than 36m3. • Steam cleaners must not be used when cleaning this appliance. • The performance of your extractor will vary depending on a number of factors.
-
Page 6: Using Your Extractor
Using your extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking (you can use the timer function, detailed on page 7, for this). Control Panel (Fig. - Page 7 To activate the timer function • Press and hold the desired speed button for approximately 5 seconds to activate a 15 minute timer for that speed. The selected speed’s indicator should flash. Hold the same button for approximately 5 seconds to cancel the timer. Please note that the intensive speed automatically switches off after approximately 6 minutes (see page 20 for more information).
-
Page 8: Care And Maintenance
Care and maintenance IMPORTANT: DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY SUPPLY. Cleaning You should use a non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. - Page 9 Please note: After 30 hours of use the light button will flash to signal that the filters needs to be cleaned. With the extractor off, press and hold the lamp button until it stops flashing to reset after cleaning. To remove the grease filters, lift the catch on the handle on the grease filter.
-
Page 10: Changing The Light
Changing the light bulbs If one or more of your LED units fail, please contact CDA Customer Care using the contact details below to arrange a service visit. Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road,... -
Page 11: Installation
Please take care and wear adequate PPE when handling. Installation preparation - height When the extractor is to be installed above a CDA electric hob, the minimum distance between the hob and the bottom edge of the extractor must exceed 650mm. - Page 12 Please note that each chimney piece is 660mm in height Fig. 3 Fig. 4 Fig. 5...
- Page 13 There are images on page 12 showing the extractor dimensions (Fig. 3) and an exploded view of the installation components. (Fig. 5). These are intended to help with installing the extractor. Place the extractor on a surface that has been sufficiently protected to prevent damage to the surface and/or extractor.
- Page 14 The underside panel can now be removed. Manoeuvre it out of position and disconnect the lamp connectors. Place the panel (Fig. 8) somewhere safe where it will neither cause nor receive damage. Fit bracket D in Fig. 5 to the top of the motor group as per Fig.
-
Page 15: Mounting The Extractor
Mounting the extractor IMPORTANT: Before cutting/drilling through any surfaces, ensure that adequate measures have been taken to ensure no electrical cables or similar lie above/behind. There should be six holes marked out on the wall to be drilled; two for the bracket and four for the side support holes. - Page 16 Ducting, ventilation and final steps For best performance and lowest noise output, we recommend the use of 150mm ducting. You can also use smaller diameter ducting but this will reduce performance and potentially increase the noise level of the extractor whilst in use. In general, the less ducting you use (i.e. distance and bends) the more efficient your extractor will be.
- Page 17 Secure the ducting to the motor outlet using a jubilee clip or similar. If you are recirculating the extracted air, fix the ducting to the recirculating bracket piece, as per Fig. 13. Use a jubilee clip or similar. Place the chimney sections on the extractor, taking care not to damage Fig.
-
Page 18: Mains Electricity Connection
Mains electricity connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A 3A FUSE. DOUBLE POLE We recommend that the appliance is SWITCHED FUSED SPUR OUTLET connected by a qualified electrician,... -
Page 19: Electrical Information
Check that the mains supply has not been switched off. Check whether the extractor still extracts on any speed. If not, check the fuse, as above. If the lights still do not work, contact CDA Customer Care using the details on page 20. (continued on page 20) - Page 20 Press and hold the light button to reset after cleaning. If any of the potential resolutions in this guide do not resolve your issue, please contact CDA Customer Care using the contact details below. Contact CDA Customer Care...
- Page 21 NOTES:...
- Page 22 NOTES:...
-
Page 23: Energy Efficiency Information
Measured power consumption in 0.45 standby mode Sound power level 91 (B) Hood c i f 36 (A) Hood E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice. - Page 24 For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.eu Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 F: 01949 862 003 E: customer.care@cda.eu www.cda.eu...
