- Page 1 ACM In-Line MIXED FLOW FANS Installation and Wiring Instructions Stock Ref. N° ACM250 17110010B ACM315 17112010B 220-240V~50Hz IPX4 PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH THE ILLUSTRATIONS. PLEASE SAVE THESE INSTRUCTIONS...
- Page 2 C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. D. The Fan should only be used in conjunction with the appropriate Vent-Axia products. E. It is recommended that the connection to the fan connecter terminals is made with flexible cable.
- Page 3 FIG 1 ACM250 (17110010B) & ACM315 (17112010B) WIRING DIAGRAM 1 Phase Supply (220-240V 50 Hz). SWITCHED FUSED SPUR FAN TERMINAL OVER-HEATING PROTECTION. The ACM Fans motor is fitted with Thermal Overload Protection. This will automatically switch the fan off in the event of a fault condition.
- Page 4 Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:- •...
