Congratulations
on your purchase of the ex tend
•
Your complete satisfaction is very important to us.
Gefen's line of KVM (Keyboard Video & Mouse), DVI, ADC, USB, switches,
extenders, converters and hubs is designed to make computer use more
comfortable, more productive and less expensive.
KVM switches allow access to multiple computers from a single keyboard,
while the extenders give the user control over a computer up to 330 feet
away from the work area.
The ex tend it line offers solutions for noise, space and security concerns,
• •
data center control, information distribution, conference room presentation,
and school and corporate training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible
price. Included in that price is a lifetime of free support from a team of out-
standing engineers.
Introduction
The ex tend it ADC Repeater extends the length of any DVI cable. It extends
• •
the distance between computers equipped with ADC or DVI graphic
cards and ADC monitors.
The ADC Repeater enables you to relocate your computer to a
safe, quiet and clutter-free environment.
How it works:
P
lace your digital flat panel display as far as you need it to go.
One side of the ex tend it ADC Repeater is connected to a long
• •
DVI (male to male) cable which is connected to the computer ADC
graphic port via the ADC to DVI adapter. The ADC Repeater output is
connected directly to the flat panel display. A universal 24 volt power
supply and USB are also connected to the ADC Repeater.
