Summary of Contents for Gefen GEF-3GSDI-FO-141
- Page 1 3GSDI Fiber Optic Extender GEF-3GSDI-FO-141 User Manual www.gefenpro.com...
- Page 2 Notice Gefen LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 3GSDI Fiber Optic Extender is a trademark of Gefen LLC © 2011 Gefen, LLC. All rights reserved.
-
Page 3: Table Of Contents
CONTENTS Introduction Operation Notes Features Connector Layout Connector Descriptions Connecting and Operating The 3GSDI Fiber Optic Extender Troubleshooting Specifi cations Warranty... -
Page 4: Introduction
Complex distribution units allow for professional DVI, 3G-SDI, and HDMI signals to be routed and converted easily and seamlessly, while being backed up by a renowned and dependable technical support team. Gefen invites you to explore the GefenPRO product line and hopes that you fi nd the solution that fi... -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE 3GSDI FIBER OPTIC EXTENDER • The GefenPRO 3GSDI Fiber Optic Extender will connect two 3G-SDI devices using an ST-terminated fi ber cable to a distance of up to 12 miles (20 kilometers.). -
Page 6: Features
FEATURES Features • Extends 3G-SDI up to 12 miles (20 kilometers) using single-mode fi ber. • Transports Multi-rate HD-SDI Digital Video over one fi ber optic cable. • Supports SMPTE-424M (3G-SDI), SMPTE-292M (HD-SDI), or SMPTE- 259M (SDI) specifi cations. • Automatic Input Equalization •... -
Page 7: Connector Layout
CONNECTOR LAYOUT Receiver Sender (shown with protective cover) -
Page 8: Connector Descriptions
CONNECTOR DESCRIPTIONS BNC Output Connector Connect the Receiver to the input of the SDI display. ST Fiber Connector Input Connect the ST-terminated fi ber cable to this connector. 5 V DC Power Supply Connector (Receiver) Connect this cable to the included 5 V DC power supply. BNC Input Connector Connect the Sender to the output of the SDI source. - Page 9 CONNECTING THE 3GSDI FIBER OPTIC EXTENDER How to Connect the 3GSDI Fiber Optic Extender Connect the Sender of the GefenPRO 3GSDI Fiber Optic Extender to the 3G-SDI source equipment via the BNC connector. Remove the locking protective cover from the fi ber connector of the Sender and connect one end of the fi...
-
Page 10: Troubleshooting
TROUBLESHOOTING No picture / display shows a blank screen • Ensure that all jacks that are used by the 5 V DC power supplies are fi rmly connected. • Ensure that the SDI connector is fi rmly plugged in to the SDI source and SDI display. -
Page 11: Specifi Cations
SPECIFICATIONS Signal Formats.....SMPTE-424M 3G HD-SDI, SMPTE-292M HD-SDI, SMPTE-259M SDI Input Impedance....................75 Ω Data Rate..................3.0 Gbps (max.) Signal Level................800 mV p-p (± 50 mV) Input Connector...................BNC Female Output Connector................BNC Female Optical Fiber Connector..................ST Number of Fibers....................1 Power Supply....................5 V DC Power Consumption................2.5 W (max.) Power Budget....................16 dB Operating Temperature................ -
Page 12: Warranty
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 13 Rev A3 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefenpro.com support@gefenpro.com This product uses UL listed power supplies.
