WARNING
Combustion by-products produced when using this product contain chemicals
known to the State of California to cause cancer, birth defects, or other
reproductive harm.
Natural Gas Grill
4638220
ASSEMBLY, USE AND
CARE MANUAL
THIS GRILL IS FOR
OUTDOOR USE ONLY
CAUTION:
Read and follow all safety
statements, assembly instructions,
and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
these instructions with consumer.
CONSUMER:
Keep this manual for
future reference.
WARNING
!
Failure to follow all manufacturer's
instructions could result in serious
personal injury and/or property
damage.
CAUTION
!
Some parts may contain sharp edges
– especially as noted in the manual!
Wear protective gloves if necessary.
If you have any questions or need
assistance during assembly, please
call 1-800-241-7548.
Visit us on the web at:
www.charbroil.com
4638220 / 0–4165056 (01-04-02)
Leave

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quickset 4638220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil Quickset 4638220

Summary of Contents for Char-Broil Quickset 4638220

  • Page 1 Some parts may contain sharp edges – especially as noted in the manual! Wear protective gloves if necessary. If you have any questions or need assistance during assembly, please call 1-800-241-7548. Visit us on the web at: www.charbroil.com 4638220 / 0–4165056 (01-04-02)

  • Page 2: For Your Safety

    Date Purchased CAUTION • For residential use only. Do not use for commercial cooking. 2 • 4638220 Installation Safety Precautions • This grill is designed for natural gas use at 7 inch water column supply pressure. Verify supply pressure with your local gas company.

  • Page 3: Table Of Contents

    TruFlame® are registered Trademarks of the W.C. Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™,...

  • Page 4: Parts List

    Parts List - Model 4638220 Key Qty. Description Warming Rack ....4152125 Cooking Grate ....4152741 Leg Extender Assembly .

  • Page 5: Exploded View

    4638220 • 5...
  • Page 6 ATTACHES TO RIGHT SIDE. NOTE: To prevent scratching, lay grill on packing material to assemble. 6 • 4638220 Remove end of rating label located on your grill’s back panel (see parts list to identify) and apply to your warranty card in box #5.
  • Page 7 2. Position Drip VapoRISER Bar as shown and place above burner, resting on supports at each end of grill bottom. Briquet Placement FRONT BACK BACK FRONT Text to inside Press Notch Do not let briquets cover burner port holes. 4638220 • 7...
  • Page 8 1. Insert pivot wire of SwingAway into grill lid. Flex leg wires to insert into grill bottom (see inset). 2. Place cooking grate into grill bottom. Back of SwingAway pointing upward. Pivot wire 8 • 4638220 Hinge pin and hitch pin wire...
  • Page 9 (not included) to hang from grease clip. CAUTION • Failure to install can in clip will cause hot grease to drip from bottom of grill with risk of fire or property damage. Center of grill bottom Grease clip 4638220 • 9...
  • Page 10 1. Beneath control panel, attach 12’ natural gas hose to valve. 2. Tighten the connection with an adjustable wrench. 3. LEAK TEST AS SHOWN ON PAGE 12 BEFORE USING GRILL. 10 • 4638220...

  • Page 11: Connecting Your Grill To The Natural Gas Source

    Movement of the grill can cause Breakage of metal pipe. Socket Sleeve Insert cover in socket when hose is removed Push sleeve back to attach Socket Plug To disconnect, push sleeve back and pull WARNING Hose Plug 4638220 • 11...

  • Page 12: For Safe Use Of Your Grill And To Avoid Serious Injury

    • Apartment Dwellers: Check with management to learn the requirements and fire codes for using an Gas Grill in an apartment. If allowed use outside on the ground floor with a three (3) foot clearance from walls or rails. Do not use on or under balconies made of wood.

  • Page 13: Grill Lid

    Do not apply a caustic grill/oven Wash grate and drip vaporiser bar with ash with warm soapy water and wipe dry. Because of glass-like composition, most Wash with mild detergent or nonabrasive This grate will eventually decompose and 4638220 • 13...

  • Page 14: Grease Clip

    Burner Tube Short Ignitor Wire 14 • 4638220 7. If grill is to be stored, coat burner lightly with cooking oil. Wrap in protective cover to keep insects out. 8. If not storing grill after cleaning, hold briquet grate and burner together angle into grill bottom (D).

  • Page 15: Storing Your Grill

    Clean cooking grate and discard old briquets. • Store in dry location. • Cover grill if stored outdoors. Choose from a variety of grill covers offered by Char-Broil. • Storage of grill indoors is permissible ONLY if gas source is disconnected. •...

  • Page 16: Troubleshooting

    Flashback... Burner and/or burner tubes are (fire in burner tube(s) blocked. 16 • 4638220 Prevention/Cure Clean wires and/or electrode with rubbing alcohol and clean swab. Wipe dry with cloth. Replace electrode. Reconnect or replace ignitor wire.
