Char-Broil Quickset 463811903 Installer/Assembler

Parts List - Model 463811903
Key Qty. Description Part # Key Qty. Description
A 1 Lower SwingAway . . . . . . . . . . . . . . . . . . . . 4152125 W 1 Grease Clip . . . . . . . . . . . . . . . . . . . . . . . . . 5156607
B 1 Cooking Grate . . . . . . . . . . . . . . . . . . . . . . . 4152741 X 1 LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . 4158015
C 1 Condiment Basket . . . . . . . . . . . . . . . . . . . . 4154269 1 Hardware Bag, Cart . . . . . . . . . . . . . . . . . . . 4254047
D 1 Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4154488 2 Hardware Bag, Shelves . . . . . . . . . . . . . . . . 4254050
E 2 Side Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . 4154543 Replacement Ignition Module Bag . . . . . . . . . . . . . . . . 4506709
F 2 Wheel Assembly. . . . . . . . . . . . . . . . . . . . . . 4310002
G 1 Upper SwingAway . . . . . . . . . . . . . . . . . . . . 4156449
H 1 Back Support Brace . . . . . . . . . . . . . . . . . . . 4500250
I 1 V Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4500291
J 1 Tank Support Bracket . . . . . . . . . . . . . . . . . . 4502093
K 2 Leg Assembly . . . . . . . . . . . . . . . . . . . . . . . . 4502097
L 1 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . 4502232
M 1 Side Support Brace . . . . . . . . . . . . . . . . . . . 4502373
N 4 #10x1/2", T-20, Self-Tap Screw . . . . . . . . . . 4080043
O 2 Valve Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . 4156172
P 1 Burner/Collector Assembly . . . . . . . . . . . . . . 4505085
Q 1 Control Panel Assembly . . . . . . . . . . . . . . . . 4530116
R 2 Control Knob . . . . . . . . . . . . . . . . . . . . . . . . 4154470
S 1 Grill Bottom. . . . . . . . . . . . . . . . . . . . . . . . . . 4580468
T 1 Grill Lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4581964
Optional Assembly Hardware
U 1 Tank Retainer Wire. . . . . . . . . . . . . . . . . . . . 4151018
We realize some customers prefer to use tools.
V 1 Logo Plate . . . . . . . . . . . . . . . . . . . . . . . . . . 4157147 nuts have been provided for you to use.
V
Part#
B
I
P
S
H
E
F
U
J
Optional hex X
D
T
G
A
E
W
K
N
Q
C
N
R
N
O
M
Q
O
Q
L
K
F
463811903
ASSEMBLY MANUAL
THIS GRILL IS FOR
OUTDOOR USE ONLY
CAUTION: Read and follow all safety
statements, assembly instructions, and use
and care directions before attempting to
assemble and cook.
INSTALLER/ASSEMBLER:
instructions with consumer.
CONSUMER: Keep this manual for future
reference.
WARNING
!
Failure to follow all manufacturer's
instructions could result in serious personal
injury and/or property damage.
CAUTION
!
Some parts may contain sharp edges –
especially as noted in the manual! Wear
protective gloves if necessary.
If you have any questions or need assistance
during assembly, please call 1-800-241-7548.
Visit us on the web at:
www.charbroil.com
463811903 / 0–4165207 (11-25-02) C O L U M B U S , G A
