  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    Table of ConTenTs safeTY ....................4 Class B emissions limits ......................4 Important Safety Instruction....................... 4 Precautions..........................5 Eye Safety Warnings ......................... 6 InTRoDUCTIon .................. 7 Package overview ........................7 Product overview ........................8 InsTallaTIon ................... 11 Connecting the Projector ......................11 Powering On/Off the Projector....................
  • Page 3 Compatible resolutions ......................67 True 3D video compatibility table ....................68 Telnet commands ........................69 AMX device discovery commands.................... 69 PJLink™ supported commands....................70 Trademarks ..........................71 Ceiling mount installation......................72 Optoma global offices ....................... 73 Regulation & Safety Notices ..................... 74 English...

  • Page 4: Safety

    Something has fallen in the projector or something is loose inside. Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡...

  • Page 5: Precautions

    precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. Warning ‡ Do not look into the projector’s lens when the lamp is on. The bright light may hurt your eyes. As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015. ‡...

  • Page 6: Eye Safety Warnings

    eye safety Warnings ‡ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ‡ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen.

  • Page 7: Introduction

    InTRoDUCTIon package overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact Optoma customer service.  User’s Manual  Warranty Card  Basic User’s Manual projector with lens Remote Control power Cord 1.8m...

  • Page 8: Product Overview

    InTRoDUCTIon product overview Main unit notee: ‡ Allow at least 50 cm clearance around the intake and exhaust vent. ‡ Allow distance 30 cm from ceiling. ‡ Ensure that the intake vents do not recycle hot air from the exhaust vent. Item Item Exhaust Vent...
  • Page 9 InTRoDUCTIon Connection ports Item Item Power Socket 12V OUT HDMI1 HDMI2 / (MHL support) MOUSE / SERVICE RS-232C USB READER / DISPLAY VGA-OUT / YPbPr IR Receiver VGA-IN / YPbPr AUDIO IN RJ-45 AUDIO OUT English...
  • Page 10 InTRoDUCTIon Remote control Item Item Power On/Off Menu/2 VGA/5 Freeze Switch USB mouse Left click Four Directional Select Keys USB mouse Right click Enter Page+ Laser (Do noT poInT In eYes) Volume +/- Page- 3D/3 V Keystone +/- Video/6 User3/9 /1(Number Button for password input) HDMI/4 Resync...

  • Page 11: Installation

    InsTallaTIon Connecting the projector Connect to notebook Item Item DVI/HDMI Cable (Optional Accessory) Power Cord HDMI Cable (Optional Accessory) RS232 Cable (Optional Accessory) VGA Input Cable Audio Cable (Optional Accessory) notee: Due to the difference in applications for each country, some regions may have different accessories. English...
  • Page 12 InsTallaTIon Connect to Video sources Item Item HDMI Cable (Optional Accessory) Power Cord SCART RGB/S-Video Adapter (Optional Accessory) notee: Due to the difference in applications for each country, some regions may have different accessories. notee: 12V OUT is a programmable trigger. English...

  • Page 13: Powering On/Off The Projector

    InsTallaTIon powering on/off the projector powering on the projector Remove the lens cover. Connect the power cord to the projector. Turn On the connected devices. notee: Turn on the projector first and then select the signal sources. Ensure the Power LED is steady red and then press the power button to turn On the projector. The projector’s startup logo screen displays and connected devices are detected.

  • Page 14: Adjusting The Projected Image

    InsTallaTIon powering off the projector Press the “ ” button on the remote control or (poWeR) button on the panel of the projector to turn off the projector. First push of button will display the following message on the screen. Press the button again to confirm the shut down.
  • Page 15 InsTallaTIon adjusting projection Image size (1080p_1.2x) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of 16e:9 (feet) (feet) screen Width Height Width Height Wide Tele Wide Tele (feet) 0.66 0.37 2.18 1.23 0.81 0.97 2.66 3.19...
  • Page 16 InsTallaTIon adjusting projection Image size (1080p_1.5x) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of 16e:9 (feet) (feet) screen Width Height Width Height Wide Tele Wide Tele (feet) 0.66 0.37 2.18 1.23 0.92 1.39 3.03 4.55...
  • Page 17 InsTallaTIon adjusting projection Image size (1080p_sT) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of 16e:9 (feet) (feet) screen Width Height Width Height (feet) 0.66 0.37 2.18 1.23 0.33 1.09 0.06 0.18 0.89 0.50 2.91 1.63...
  • Page 18 InsTallaTIon adjusting projection Image size (WUXGa) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of (feet) (feet) 16e:10 screen Width Height Width Height Wide Tele Wide Tele (feet) 0.65 0.40 2.12 1.32 0.90 1.35 2.95 4.43...
  • Page 19 InsTallaTIon adjusting projection Image size (XGa) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of 4e:3 (feet) (feet) screen Width Height Width Height Wide Tele Wide Tele (feet) 0.61 0.46 2.00 1.50 0.98 1.17 3.20 3.84...
  • Page 20 InsTallaTIon adjusting projection Image size (WXGa_1.2x) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of (feet) (feet) 16e:10 screen Width Height Width Height Wide Tele Wide Tele (feet) 0.65 0.40 2.12 1.32 0.83 0.99 2.71 3.26...
  • Page 21 InsTallaTIon adjusting projection Image size (WXGa_sT) screen size W X H (16e:9) projection Distance (D) Diagonal length offset (a) (inch) size of (feet) (feet) 16e:10 screen Width Height Width Height (feet) 0.65 0.40 2.12 1.32 0.34 1.11 0.05 0.15 0.86 0.54 2.83 1.77...

  • Page 22: User Controls

    UseR ConTRols Remote control Using the Remote Control Refer to the “Powering Off the Projector” on page 14. Power On/Off Refer to the “Powering On the Projector” on page 13. When connecting your PC to the projector through USB, press “Mouse Switch” to activate/ inactivate the /Switch mouse mode and control your PC using the remote.

  • Page 23: On-Screen Display Menus

    UseR ConTRols Using the Remote Control Video/6 Press “Video” to choose Composite video source. User 1/7 Refer to the “User1 / User2 / User3” on page 41 User 2/8 Refer to the “User1 / User2 / User3” on page 41 User 3/9 Refer to the “User1 / User2 / User3”...

  • Page 24: Menu Tree

    UseR ConTRols Menu Tree notee: ‡ (#) “Color” and “Tint” is only supported in for YUV video sources. ‡ (*) “3D” is only available when a compatible signal is supplied. English...
  • Page 25 UseR ConTRols English...
  • Page 26 UseR ConTRols English...
  • Page 27 UseR ConTRols Display menu Image settings Enter the Image Settings menu. See page 28 for more details. Enter the 3D menu. See page 30 for more details. aspect Ratio Use this function to choose your desired aspect ratio. ‡ 4e:3e: This format is for 4x3 input sources not enhanced for Wide screen TV. ‡...

  • Page 28: Display / Image Settings

    UseR ConTRols Zoom ‡ Press ◄ to reduce the size of the image. ‡ Press ► to magnify an image on the projected screen. Image shift Shifts the projected image position horizontally or vertically. ‡ Press ◄► to move the image horizontally on the projected screen. ‡...
  • Page 29 UseR ConTRols brightness Adjust the brightness of the image. ‡ Press ◄ to darken image. ‡ Press ► to lighten the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. ‡ Press ◄...

  • Page 30: Display / 3D

    UseR ConTRols Display / 3D 3D Mode Dlp linke: Select DLP Link to use optimized settings for DLP Link 3D Glasses. ‡ ‡ IRe: Select IR to use optimized settings for IR-based 3D images. ‡ offe: Select “Off” to turn off 3D mode. 3D2D Press ◄►...

  • Page 31: Display / Geometric Correction

    UseR ConTRols Display / Geometric Correction four Corners adjustment Select “Yes” for Geometric Correction adjustment. Use ▲▼◄► key select corner for adjustment. Press (Enter) button and adjust corners by ▲▼◄►. Press Enter and press ↑↓ to select Geometric Correction. Press ▲▼ to select Four Corner Adjustment. In the Four Corner Adjustment menu, use ▲▼◄► key and press (Enter) button to select a specific corner.

  • Page 32: Display / Image Settings / Color Setting

    UseR ConTRols Display / Image settings / Color setting brilliantColor™ This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture. The range is from 1 to 10. If you prefer a stronger enhanced image, adjust toward the maximum setting.

  • Page 33: Display / Image Settings / Signal

    UseR ConTRols Display / Image settings / signal automatic Set Automatic to On or Off to lock or unlock the Phase and Frequency features. ‡ Disablee: Off auto lock. ‡ enablee: On auto lock. frequency Change the display data frequency to match the frequency of your computer’s graphics card. If you experience a vertical flickering bar, use this function to make an adjustment.

  • Page 34: Display / Image Settings / Color Setting / Color Matching

    UseR ConTRols Display / Image settings / Color setting / Color Matching Colors (except White) Press ◄► to select a color. Press ▲▼ to select Hue, Saturation, or Gain and press ◄► to adjust the settings. White Press ◄► to select White. Press ▲▼...
  • Page 35 UseR ConTRols Mute Toggle the audio on or off. ‡ offe: The speaker volume and audio out are turned on. ‡ one: The speaker volume and audio out are turned off. Volume Press ◄ to decrease the volume. Press ► to increase the volume. audio out Press ◄►...

  • Page 36: Setup / Lamp Settings

    UseR ConTRols HDMI link settings Enter the HDMI Link Settings menu. See page 40 for more information. Test pattern Display a test pattern. There are Grid, White and None. Remote settings Enter the Remote Settings menu. See page 41 for more information. projector ID Select a two digit projector ID from 00 through 99.

  • Page 37: Setup / Power Settings

    UseR ConTRols setup / power settings Direct power on Enable or disable Direct Power On. ‡ one: The projector powers on automatically when AC power is supplied. ‡ offe: The projector must be powered on as normal. signal power on Enable or disable Signal Power On.

  • Page 38: Setup / Security

    UseR ConTRols power Mode (standby) ‡ eco.e: Choose “Eco.” to save power dissipation further < 0.5W. ‡ activee: Choose “Active” to return to normal standby mode . notee: ‡ When Power Mode (Standby) is set to Eco., the VGA & Audio pass-through and RJ45 would be deactivated.
  • Page 39 UseR ConTRols If the projector is in use and the Security Timer is active, the following screen displays 60 seconds before the password is required. notee: If the incorrect password is entered three times, the device auto shutdowns after 10 seconds. Change password Use this submenu to change the security password for the projector.

  • Page 40: Setup / Hdmi Link Settings

    UseR ConTRols setup / HDMI link settings HDMI link Enable/disable the HDMI Link function. The inclusive TV, power on link, and power off link options will only available if the setting is set to “On”. notee: When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them on the same power on or power off status using the HDMI Link control feature in the projector’s OSD.

  • Page 41: Setup / Remote Settings

    UseR ConTRols setup / Remote settings IR function Enable or Disable projector’s IR function. User1 / User2 / User3 Set User1, User2, User3 key as a hotkey for LAN, Brightness, Contrast, Sleep Timer, Color Matching, Color Temp, Gamma, Projection, Lamp Settings, Zoom, Test Pattern, Freeze, Network Display, USB Display, Multimedia, HDMI2 function.
  • Page 42 UseR ConTRols High altitude Adjust the fan speed to reflect the environment. ‡ one: Increases fan speed for high temperature, humidity, or altitude. ‡ offe: Regular fan speed for normal conditions. Display Mode lock Choose “On” or “Off” to lock or unlock adjusting display mode settings. Keypad lock Lock the buttons on the projector top panel.

  • Page 43: Setup / Options / Language

    UseR ConTRols setup / options / language language (enter) button into the sub menu and then use the Up (▲) or Down Choose the multilingual OSD menu. Press (▼) key to select your preferred language. setup / options / Menu settings Menu location Select the menu location on the display screen.

  • Page 44: Setup / Options / Input Source

    UseR ConTRols setup / options / Input source Input source (enter) button to finalize the Use this option to select input sources. Press ▲▼ to select a source. Press selection. Network Wlan Wlane: Off/On ‡ ‡ network statuse: Read only. ‡...

  • Page 45: Network / Lan

    UseR ConTRols network / lan notee: Network sub-menu can only be accessed if a network cable is connected. If the connection is successful, the OSD display will show the following dialogue box. ‡ network statee: To display network information. MaC addresse: Read only. ‡...

  • Page 46: Network / Control

    UseR ConTRols network / Control Crestron Press ◄► to check to enable/disable Crestron. Port: 41794 extron Press ◄► to check to enable/disable Extron. Port: 2023 pJ link Press ◄► to check to enable/disable PJ Link. Port: 4352 aMX Device Discovery Press ◄►...
  • Page 47 UseR ConTRols Information View the projector information as listed below: ‡ Regulatory ‡ Serial Number ‡ Source ‡ Resolution ‡ Refresh Rate ‡ Display Mode ‡ Power Mode (Standby) ‡ Lamp Hours ‡ Network Status ‡ IP Address ‡ Projector ID ‡...

  • Page 48: Media

    UseR ConTRols Media How to set up file type for multimedia with USB notee: ‡ A USB flash disk must be plugged into the projector if you want to use the multimedia USB function. ‡ Please don’t connect USB port for camera since it would be exist compatibility problem. Follow these steps to playback the Photo, Video, or Music files on your projector: Connect the power cable with AC adapter and turn on the projector by pressing the Power button.
  • Page 49 UseR ConTRols Access the USB menu and select the multimedia files: Photo, or Document. Or select the Settings option to change settings for Photo, or Document. Select the file you want to open. The Multimedia Setting allow you to change settings for Display ratio and Interval time of the Photo and Document.
  • Page 50 UseR ConTRols Document support format pages/lines file format support Version size limitation Comment limitation Adobe PDF PDF 1.0 Up to 1000 pages Up to 75 MB (One File) PDF 1.1 PDF 1.2 PDF 1.3 PDF 1.4 MS Word British Word 95 Because office Up to 100 MB Not support Bold Text in...
  • Page 51 UseR ConTRols Mirroring a smart device The following procedure requires a tethered connection from the smart device to the project. To mirror to the projector: Connect the power cable with AC adapter and turn on the projector by pressing the Power button. Connect the projector and your mobile device with a USB cable.
  • Page 52 (Android) and install the HDCast Pro app on your mobile device. If you are using a laptop, download HDCast Pro app from website. www.optoma.com/hdcastpro Plug in a Wi-Fi dongle (Optional) to your projector. Connect your portable device via Wi-Fi to the projector. An example connection parameters are as follows: ±...

  • Page 53: Lan_Rj45

    * Some Windows 10 is not support extension mode but will be completed in 2017. lan_RJ45 For simplicity and ease of operation, the Optoma projector provides diverse networking and remote management features. The LAN/RJ45 function of the projector through a network, such as remotely manage: Power On/Off, Brightness and Contrast settings.
  • Page 54 UseR ConTRols For more detail of information about the diverse types of external devices which can be connected to the LAN/RJ45 port and remote/control the projector, as well as the related control commands supporting for each external device, kindly please get contact with the Support-Service directly. lan_RJ45 Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop).
  • Page 55 UseR ConTRols In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). Click Properties. Fill in the IP address and Subnet mask, then press OK. English...
  • Page 56 UseR ConTRols Press (Menu) button on the projector. Select OSD -> Network -> Lan. After getting into Network Status, input the following: ± DHCP: Off ± IP Address: 192.168.0.100 ± Subnet Mask: 255.255.255.0 ± Gateway: 192.168.0.254 ± DNS: 192.168.0.51 ± DNS2: 8.8.4.4 Press (Enter) button to confirm settings.
  • Page 57 UseR ConTRols Rs232 by Telnet function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. English...
  • Page 58 UseR ConTRols Quick start-Guide for “Rs232 by TelneT” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector. Make sure that “Windows Firewall” setting to be disabled in case of “TELNET” function filtering out by laptop/PC. Start =>...
  • Page 59 UseR ConTRols How to have TelneT enabled in Windows VIsTa / 7 By default installation for Windows VISTA, “TELNET” function is not included. But end-user can have it by way of “Turn Windows features On or Off” to be enabled. Open “Control Panel”...
  • Page 60 UseR ConTRols Have “Telnet Client” option checked, then press “OK” button. specsheet for “Rs232 by TelneT” e: Telnet: TCP. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team). Telnet utility: Windows “TELNET.exe” (console mode). Disconnection for RS232-by-Telnet control normally: Close Windows Telnet utility directly after TELNET connection ready.

  • Page 61: Appendices

    appenDICes Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”...
  • Page 62 appenDICes other The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Lamp burns out or makes a popping sound ‡ When the lamp reaches its end of life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn on until the lamp module has been replaced.
  • Page 63 appenDICes LED states On Screen Messages ‡ Fan failed: The projector will switch off automatically. ‡ Over temperature: The projector will switch off automatically. ‡ Replacing the lamp: Lamp is approaching the end of its rated life. Replacement suggested. Warning: Only use genuine lamps. Remote control If the remote control does not work ‡...

  • Page 64: Replacing The Lamp

    appenDICes Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you will receive a warning message. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.
  • Page 65 appenDICes English...
  • Page 66 appenDICes lamp replacing proceduree: Switch off the power to the projector by pressing the Power button. Allow the projector to cool down at least 30 minutes. Disconnect the power cord. Remove two screws on the lamp compartment cover.  Remove the lamp compartment cover. ...

  • Page 67: Compatible Resolutions

    appenDICes Compatible resolutions HDMI 1 H-sYnC V-sYnC signal Resolution CoMponenT VGa (analog) HDMI 2/MHl (KHz) (Hz) (Digital) 720 x 400 31.5 70.1 —   31.5 640 x 480 —   640 x 480 66.667 —   37.86 72.8 640 x 480 —...

  • Page 68: True 3D Video Compatibility Table

    appenDICes HDMI 1 H-sYnC V-sYnC signal Resolution CoMponenT VGa (analog) HDMI 2/MHl (KHz) (Hz) (Digital) 15.734 480i —   SDTV 576i 15.625 —   31.3 576p —   EDTV 480p 31.5 —   37.5 720p — ...

  • Page 69: Telnet Commands

    Standby State      Defined by Optoma 2 or 3 Digit. Fix code One Digit~ One Digit Per item Definition Fix code One Digit See the Follow content notee: For wide screen resolution (WXGA), the compatibility support is dependent on Notebook/PC models.

  • Page 70: Pjlink™ Supported Commands

    Inquiry about the projector name The projector name set on the NETWORK menu or the ProjectorView Setup window is returned INF1? Inquiry about the manufacturer name “Optoma” is returned. INF2? Inquiry about the model name “XXXXX” is returned. INF0? Inquiry about other information No other information is available.

  • Page 71: Trademarks

    appenDICes Trademarks ‡ DLP is trademarks of Texas Instruments. ‡ IBM is a trademark or registered trademark of International Business Machines Corporation. ‡ Macintosh, Mac OS X, iMac, and PowerBook are trademarks of Apple Inc., registered in the U.S. and other countries.

  • Page 72: Ceiling Mount Installation

    Ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attached a mount to the projector met the following specifications: ±...

  • Page 73: Optoma Global Offices

    Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...

  • Page 74: Regulation & Safety Notices

    appenDICes Regulation & safety notices This appendix lists the general notices of your Projector. fCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 75 www.optoma.com...
