Acl - Observa Telecom TD851W User Manual

Step 1: Select "Enable" (show in Figure 4-45).
Step 2: Enter "yahoo.com" in the Keyword field.
Step 3: Finally click the AddKeyword to save the entry.
Note:
After configuration, you need to click the Save button appeared on the left panel so that your
configuration can still take effect after the Router reboots.

4.5.4 ACL

Choose "Firewall→ACL", you can see the next screen (shown in Figure 4-46). ACL function is
used to specify which services are accessible from LAN or WAN side.
Direction Select: The direction of the ACL entry, it can be LAN or WAN.
1) LAN
If "LAN" is selected, you can see the next screen (shown in Figure 4-47)
TD851W 150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-46
68
