4.3.1 Route

4.3.1.1 Static Route
Choose "Advanced→Route→Static Route" menu, you can configure the routing information in
the next screen (shown in Figure 4-24). Here you can add or delete IP routes.
Enable: Check the box to enable this function.
Destination: Enter the IP network address of the final destination. It can be a subnet IP or a
host address. All zeros indicate that the route entry should be used for all destinations for
which no other route is defined.
Subnet Mask: Enter the subnet mask of the destination.
Next Hop: The IP address of the next hop through which traffic will forward the destination.
Interface: Select the interface to which a static route is to be applied.
Click the Add Route button to add the new route in the Static Route Table.
The Static Route Table shows the current static route entries.
Note:
After configuration, you need to click the Save button appeared on the left panel so that your
configuration can still take effect after the Router reboots.
4.3.1.2 RIP
Choose "Advanced→Route→RIP" menu, you can configure the RIP settings in the next screen
(shown in Figure 4-25). RIP is an internet protocol you can setup to share routing table information
with other routing devices.
TD851W 150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-24
43
