Note:
If you want to enable the WDS, please go to the page WLAN->Basic, and select the "Mode" to be
AP+WDS.
Enable WDS: Select to enable WDS.
Add WDS AP: To add MAC addresses of other Access Point, follow the steps below.
Step 1. Enter MAC Address of the Access Point to communicate with in "MAC Address"
field.
Step 2. Give a description for that Access Point in "Comment" field.
Step 3. Click Apply Changes button to save the MAC address to "Current WDS AP List".
Note:
If changes are made, after clicking Apply Changes button, a Save button will appear on the left
panel. You need to click the Save button to make your changes take effect.

4.3 Advanced

Choose "Advanced", you can see the next submenus:
Click any of them, and you will be able to configure the corresponding function.
TD851W 150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-23
