Observa Telecom TD851W User Manual page 36

Radio Power (Percent): Here you can specify the Radio Power of Router. You can select
High, Middle or Low which you would like. High is the default setting and is recommended.
Associated Clients: Click the Show Active Clients button to view the information of
wireless clients that connects to the ADSL Router.
Click Apply Changes button to save your changes.
Note:
After configuration, you need to click the Save button appeared on the left panel so that your
configuration can still take effect after the Router reboots.
4.2.3.2 Security
Choose "Setup→WLAN→Security" menu, and you will see the Wireless Security Setup screen
(shown in Figure 4-15). Here you can configure the security settings of your wireless network.
There are six encryptions supported by the Router: WEP, WPA (TKIP), WPA (AES), WPA2 (AES),
WPA2 (TKIP) and WPA2 Mixed.
Encryption: There are six encryptions supported by the Router: WEP, WPA (TKIP), WPA
(AES), WPA2 (AES), WPA2 (TKIP) and WPA2 Mixed.
Use 802.1x Authentication: If you want to use the authentication, check this box and then
set the port, IP address and password for the Authentication RADIUS Server.
1. WEP
WEP (Wired Equivalent Privacy) is a data privacy mechanism based on a 64-bit and 128-bit
shared key algorithm, as described in the IEEE 802.11g standard.
To configure WEP settings, select follow the steps below.
TD851W 150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-15
30
