- Page 1 Documentation KL9570 Buffer capacitor terminal Version: Date: 2017-10-20...
-
Page 3: Table Of Contents
Installation instructions for enhanced mechanical load capacity .......... 12 Connection............................ 13 3.3.1 Connection system...................... 13 3.3.2 Wiring .......................... 15 3.3.3 Connection ........................ 16 Application example........................ 17 ATEX - Special conditions (standard temperature range) ............ 18 ATEX Documentation ........................ 19 4 Appendix .............................. 20 Support and Service ........................ 20 KL9570 Version: 2.0... - Page 4 Table of contents Version: 2.0 KL9570...
-
Page 5: Foreword
The TwinCAT Technology is covered, including but not limited to the following patent applications and patents: EP0851348, US6167425 with corresponding applications or registrations in various other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany Copyright © Beckhoff Automation GmbH & Co. KG, Germany. -
Page 6: Safety Instructions
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards. -
Page 7: Documentation Issue Status
FF - firmware version HH - hardware version Example with ser. no.: 39 04 1B 01: 39 - week of production 39 4 - year of production 2004 1B - firmware version 1B 01 - hardware version 01 KL9570 Version: 2.0... -
Page 8: Product Overview
• When this voltage reaches 55 V, the KL9570 establishes a connection between terminal points 5 and • If the voltage between terminal points 2 and 6 falls below 52 V, the KL9570 disconnects terminal points 5 and 6 from each other again. -
Page 9: Technical Data
Product overview LED display The Overload LED is lit as soon as terminal points 5 and 6 are connected. Technical data Technical data KL9570/KS9570 Rated voltage 50 V Capacity 500 µF Switch-on threshold 55 V Switch-off threshold 52 V Ripple current 10 A in continuous operation Internal resistance < 10 mΩ... -
Page 10: Mounting And Wiring
Note flict with the fixing bolts of the mounting rail. To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). Version: 2.0 KL9570... -
Page 11: Fig. 3 Disassembling Of Terminal
PE power contact The power contact labeled PE can be used as a protective earth. For safety reasons this contact mates first when plugging together, and can ground short-circuit currents of up to 125 A. KL9570 Version: 2.0... -
Page 12: Installation Instructions For Enhanced Mechanical Load Capacity
Vibration 10 frequency runs in 3 axes 6 Hz < f < 60 Hz displacement 0.35 mm, constant amplitude 60.1 Hz < f < 500 Hz acceleration 5 g, constant amplitude Shocks 1000 shocks in each direction, in 3 axes 25 g, 6 ms Version: 2.0 KL9570... -
Page 13: Connection
Standard wiring (ELxxxx / KLxxxx) Fig. 5: Standard wiring The terminals of ELxxxx and KLxxxx series have been tried and tested for years. They feature integrated screwless spring force technology for fast and simple assembly. KL9570 Version: 2.0... -
Page 14: Fig. 6 Pluggable Wiring
Ultrasonically "bonded" (ultrasonically welded) conductors Ultrasonically “bonded" conductors It is also possible to connect the Standard and High Density Terminals with ultrasonically "bonded" (ultrasonically welded) conductors. In this case, please note the tables concern- Note ing the wire-size width below! Version: 2.0 KL9570... -
Page 15: Wiring
The cables are released, as usual, using the contact release with the aid of a screwdriver. See the following table for the suitable wire size width. KL9570 Version: 2.0... -
Page 16: Connection
Risk of injury through electric shock and damage to the device! Bring the Bus Terminals system into a safe, de-energized state before starting mounting, disassembly or wiring of the Bus Terminals! WARNING Fig. 9: KL9570 - pin assignment Terminal point No. Comment for connecting the external brake resistor... -
Page 17: Application Example
Bus Terminals! WARNING Function • The capacitor in the KL9570 compensates peaks in the supply voltage for the stepper motor/DC motor. • As soon as this supply voltage exceeds 55 V, the KL9570 activates the brake resistor R , which chopper then uses up the braking energy fed back from the stepper motor / DC motor connected to the KL2541. -
Page 18: Atex - Special Conditions (Standard Temperature Range)
• EN 60079-0:2012+A11:2013 • EN 60079-15:2010 Marking The Beckhoff fieldbus components with standard temperature range certified for potentially explosive areas bear one of the following markings: II 3G KEMA 10ATEX0075 X Ex nA IIC T4 Gc Ta: 0 … 55°C II 3G KEMA 10ATEX0075 X Ex nC IIC T4 Gc Ta: 0 … 55°C Version: 2.0... -
Page 19: Atex Documentation
Notes about operation of the Beckhoff terminal systems in potentially explo- sive areas (ATEX) Pay also attention to the continuative documentation Note Notes about operation of the Beckhoff terminal systems in potentially explosive areas (ATEX) that is available in the download area of the Beckhoff homepage http:\\www.beckhoff.com! KL9570... -
Page 20: Appendix
Beckhoff's branch offices and representatives Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 21 Power contact on left side......................Fig. 5 Standard wiring..........................Fig. 6 Pluggable wiring .......................... Fig. 7 High Density Terminals........................ Fig. 8 Connecting a cable on a terminal point ..................Fig. 9 KL9570 - pin assignment ......................Fig. 10 Application example........................KL9570 Version: 2.0...
