Weldclass CutForce 43P Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cutforce 43P
Cutforce 41PA
OPERATING INSTRUCTIONS
Edition 1.3
IMPORTANT!
To qualify for full 24 month warranty, you must register within 30 days of purchase. See inside for details.
Read these Operating Instructions Completely before attempting to use this machine. Save this manual and
keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for
your protection. Contact your distributor if you do not fully understand anything in this manual.

Advertisement

Table of Contents
loading

Related Manuals for Weldclass CutForce 43P

Summary of Contents for Weldclass CutForce 43P

  • Page 1 Cutforce 43P Cutforce 41PA OPERATING INSTRUCTIONS Edition 1.3 IMPORTANT! To qualify for full 24 month warranty, you must register within 30 days of purchase. See inside for details. Read these Operating Instructions Completely before attempting to use this machine. Save this manual and keep it handy for quick reference.
  • Page 2 The air regulator/filter supplied with the CF-45P machine provides the minimum level of filtration. However, we strongly recommend the WELDCLASS PLATINUM Z-20 high-performance air filter, available as an optional accessory from your Weldclass distributor. This attaches to the inlet of the existing regulator/filter and provides excellent filtration down to 1-micron.

  • Page 3: Table Of Contents

    Location ............................12 Ventilation ............................12 BASIC OPERATION ..........................13 Setup ............................13 Cutting ............................13 Travel Speed ..........................14 Piercing the work piece ........................15 Direction of Cut ..........................15 Reducing Dross for Clean Cuts .....................16 ACCESSORIES, SPARE PARTS & CIRCUIT DIAGRAMS ................17 © Weldclass 2020 | E.&O.E.
  • Page 4 Noise Can Damage Hearing ....................32 13.4.4 Work Environment Safety ....................33 13.4.5 Electricity Can Kill .........................33 13.4.6 Fumes And Gases .........................34 13.4.7 Fire & Explosive Risks ......................34 13.4.8 Sparks & Hot Metal ......................35 WARRANTY ............................35 14.1.1 Warranty Link ........................35 © Weldclass 2020 | E.&O.E.

  • Page 5: Basic Specifications

    35A @ 30% 25A @ 60% 25A @ 60% Nominal Open Circuit Voltage 313V 313V Table 1 For full machine specifications, refer to technical data plate on back of machine – or go to: www.Weldclass.com.au/WC-43P www.Weldclass.com.au/WC-41PA © Weldclass 2020 | E.&O.E.

  • Page 6: Know Your Machine

    3. Control panel Figure 1 3.2 Machine Rear 1. 240V AC Mains Power Input Lead 2. Mains Power Switch 3. Air Regulator Gauge 4. Air Regulator Adjustment Knob 5. Compressed Air Inlet Connection Figure 2 41PA © Weldclass 2020 | E.&O.E.

  • Page 7: Control Panel

    Cutforce 43 3.3 Control Panel 1. Power Indicator Light 2. Cutting Active Indicator Light 3. Error/Over Temperature Indicator Light 4. Amperage Knob 5. Compressor Error Indicator Light 41PA Figure 3 © Weldclass 2020 | E.&O.E.

  • Page 8: Symbols Chart

    – Fault Indication Negative Caution / Hazard Positive Read Instruction Hertz (cycles/sec) Manual Torch/Consumable Duty Cycle Error Output (Cutting Amperage Voltage) Active (Current) Single phase Voltage Inverter power source DC Table 2 Plasma Cutting Function © Weldclass 2020 | E.&O.E.

  • Page 9: Controls Explained

    3. Rotate Air Regulator Adjustment Knob to adjust air pressure whilst reading the air pressure on the Air Regulator Gauge. 4. Once correct Air Pressure is set push the Air Regulator Adjustment Knob down to lock it in position. Figure 5 Figure 6 Figure 7 © Weldclass 2020 | E.&O.E.

  • Page 10: Air Filter / Water Separator (43P Model Only)

    Moist or dirty air will significantly reduce cut quality and consumable life. The Cutforce 43P is supplied with a basic air filtration/moisture separator to assist with providing suitable air supply. The moisture separator is self-draining, the Air Filter Moisture Drain Tube exits out the bottom of the clear Air Filter Bowl.

  • Page 11: Compressor Error Light (41Pa Model Only)

    5 POWER & COMPRESSED AIR SUPPLY 5.1 Electrical Connection The Cutforce 43P and 41PA are designed to operate on a 15A 240V AC power supply. 5.2 Extension Leads If an extension cord must be used, it should be minimum cable core size 2.0mm for length of up to 10m, or minimum 2.5mm...

  • Page 12: Golden Rules Of Generator Use

    For further information please refer to AS 60529. Ventilation Adequate ventilation is required to provide proper cooling for the machine. Ensure that the machine is placed on a stable level surface where clean cool air can easily flow through the unit. © Weldclass 2020 | E.&O.E.

  • Page 13: Basic Operation

    6. Compressed air will continue to flow through the torch for several seconds after the cutting stops. In this post-flow mode, the arc can be restarted immediately by depressing the torch switch. Trigger Retaining Cap Tip / Nozzle © Weldclass 2020 | E.&O.E. Figure 10...

  • Page 14: Travel Speed

    Note: The speeds given here are typical for best quality cuts. Your actual speeds may vary depending on material composition, surface condition, operator technique, etc. Air cutting typically produces a rough face on stainless steel and aluminium. © Weldclass 2020 | E.&O.E.

  • Page 15: Piercing The Work Piece

    To make a square-edged cut along an inside diameter of a circle, the torch should move counter clockwise around the circle. To keep the square edge along an outside diameter cut, the torch should travel in a clockwise direction. Figure 13 © Weldclass 2020 | E.&O.E.

  • Page 16: Reducing Dross For Clean Cuts

    Usually it will need to be removed by grinding. When cutting troublesome steel, it is sometimes useful to reduce the cutting speed to produce ‘low speed dross’. Any resultant clean up can then be accomplished by scraping, not grinding. © Weldclass 2020 | E.&O.E.

  • Page 17: Accessories, Spare Parts & Circuit Diagrams

    8 ACCESSORIES, SPARE PARTS & CIRCUIT DIAGRAMS 8.1 Plasma Torch and Spares: The Plasma Torch supplied with the Cutforce 43P and 41PA is a Weldclass XTP-60 model. To view parts for this torch, see below table. Figure 14 Torch Parts Ref.

  • Page 18: Plasma Torch Pin Configuration

    Cap Safety Switch Trigger Cutting Current Pilot Arc 8.4 Machine Spare Parts for 43P For machine parts, go to www.weldclass.com.au/machines or contact your Weldclass distributor. Ref. Description Thermostat Solenoid Valve Air Pressure Regulator Earth Lead + Dinse Mains Power Cable...
  • Page 19 Cutforce 43 Figure 15 © Weldclass 2020 | E.&O.E.

  • Page 20: Machine Spare Parts For 41Pa

    8.5 Machine Spare Parts for 41PA For machine parts, go to www.weldclass.com.au/machines or contact your Weldclass distributor. Ref. Description Earth Lead + Dinse Mains Power Cable Cooling Fan Cooling Fan Earth Clamp Torch Connection Socket Plasma Torch Compressor Kit Power PCB kit...
  • Page 21 Cutforce 43 © Weldclass 2020 | E.&O.E.

  • Page 22: Primary Schematic Circuit Diagram For 43P

    8.6 Primary Schematic Circuit Diagram for 43P Figure 16 © Weldclass 2020 | E.&O.E.

  • Page 23: Primary Schematic Circuit Diagram For 41Pa

    Cutforce 43 8.7 Primary Schematic Circuit Diagram for 41PA Figure 17 © Weldclass 2020 | E.&O.E.

  • Page 24: Care & Maintenance

    Use only genuine replacement parts. Do not use modified or non-genuine parts. 9.2 Storing the Plasma Cutter When not in use the machine should be stored in the dry, dust-free and frost-free environment. © Weldclass 2020 | E.&O.E.

  • Page 25: General Guide To Plasma Cutting

    In addition to this, this machine has a pilot arc controller system. If the main arc cuts out and the torch remains to be triggered, the pilot arc will reignite. This is useful for cutting discontinuous workpieces like mesh or grids. © Weldclass 2020 | E.&O.E.

  • Page 26: Plasma Torch Parts Wear & Replacement

    • Damaged torch head It is also very important to only use genuine Weldclass consumables and parts for the plasma torch. They are engineered to suit the machine and non-genuine items may cause lack of performance, short life span, torch and machine damage and void warranty.

  • Page 27: Troubleshooting

    Cutting speed too fast Slow down travel speed Torch tilted too much Adjust tilt Material may be too thick for Several passes may be necessary capacity of plasma or find some other method to cut the material © Weldclass 2020 | E.&O.E.
  • Page 28 (2.5mm Extension cord being used is too Remove extension cord or use long shorter one. Cutting beyond the duty cycle Turn the amperage down or do capacity of the machine shorter cutting runs © Weldclass 2020 | E.&O.E.

  • Page 29: Knowledge & Resources

    13.3 General Safety Warnings 1. Maintain labels and nameplates on the plasma cutter. These carry important information. If unreadable or missing, contact Weldclass for a replacement. 2. Avoid unintentional starting. Make sure the plasma cutter is setup correctly and you are prepared to begin work before turning on the machine.
  • Page 30 12. Do not use this machine for pipe thawing. This machine was not designed for pipe thawing and will be a significant electrical & heat hazard if attempt is made to use for thawing pipe. © Weldclass 2020 | E.&O.E.

  • Page 31: Plasma Cutting Safety Instructions & Warnings

    CAUTION! Have the equipment serviced by a qualified repair person using identical replacement parts. This will ensure that the safety of the power tool is maintained. © Weldclass 2020 | E.&O.E.

  • Page 32: Personal Safety

    5. Never wear contact lenses while plasma cutting. 13.4.3 Noise Can Damage Hearing CAUTION! Noise from some processes can damage hearing. Use AS/NZS compliant ear plugs or ear muffs if the noise level is high. © Weldclass 2020 | E.&O.E.

  • Page 33: Work Environment Safety

    4. Disconnect input power before installing or servicing this equipment. Lock input power, disconnect switch open, or remove line fuses so power cannot be turned on accidentally. 5. Properly install and ground this equipment according to national, state, and local codes. © Weldclass 2020 | E.&O.E.

  • Page 34: Fumes And Gases

    Accidental contact of torch tip to metal objects can cause sparks, overheating, or fire. 1. Protect yourself and others from flying sparks and hot metal. 2. Do not operate where flying sparks can strike flammable material. 3. Remove all flammables within 10m of the plasma cutting site. © Weldclass 2020 | E.&O.E.

  • Page 35: Sparks & Hot Metal

    1. Wear an AS/NZS approved face shield or safety goggles. Side shields are recommended. 2. Wear appropriate safety equipment to protect the skin and body. WARRANTY 14.1.1 Warranty Link For full details on warranty period and terms and conditions, go to www.weldclass.com.au/WarrantyInfo © Weldclass 2020 | E.&O.E.
  • Page 36 © Weldclass 2020 | E.&O.E.
