VENT-FREE FIREPLACE
MODEL: GFD2915
GFD2921
GFDC3029
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
-- Do not store or use gasoline or other flammable vapors and liquids in vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
·
Do not try to light any appliance.
·
Do not touch any electrical switch; do not use any phone in your building.
·
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
·
If you cannot reach your gas supplier, call the fire department.
-- Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the room
in which it is installed. Provisions for adequate combustion and ventilation air must
be provided. Refer to Air For Combustion and Ventilation section on page 7 of this
manual.
INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE WITH HOMEOWNERS
FOR FUTURE REFERENCE
This appliance may be installed in an aftermarket, permanently located,
manufactured (mobile) home, where not prohibited by local codes. This appliance is
only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases.
Questions about installation, operation, or troubleshooting? Before returning to your retailer, call KOZY
WORLD PHONE NUMBER (814)643-1775
®
CAUTION – FOR YOUR SAFETY
WARNING:
This appliance is equipped
for (Natural and Propane) gas. Field
conversion is not permitted other than
between natural or propane gases.
WM- FB28D653-0804

Advertisement

loading
Need help?

Need help?

Do you have a question about the GFD2915 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kozy-World GFD2915

  • Page 1 (Natural and Propane) gas. Field conversion is not permitted other than ® between natural or propane gases. VENT-FREE FIREPLACE MODEL: GFD2915 GFD2921 GFDC3029 CAUTION – FOR YOUR SAFETY WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 2: Table Of Contents

    Read instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS ITEM NO. GFD2921 & GFD2915 GFDC3029 Input Rating 28,000 BTU/Hr 28,000 BTU/Hr 28,000 BTU/Hr...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Installation and service must be performed by a qualified installer, service agency, or local gas supplier.
  • Page 4 IMPORTANT SAFETY INFORMATION (CONTINUED) Do not place Propane/LP supply tank(s) inside any structure. Place Propane/LP supply tank(s) outdoors. This heater shall not be installed in a bedroom or bathroom. Do not use this heater as a wood-burning heater. Use only the logs provided with the heater.
  • Page 5 PRODUCT FEATURES SAFETY PILOT This heater has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/pilot is a required feature for vent-free room heaters. The ODS/pilot shuts off the heater if there is not enough fresh air. THERMOSTAT HEAT CONTROL The control automatically cycles the burner on and off to maintain a desired room temperature.
  • Page 6 UNPACKING Remove top inner pack. Tilt carton so that fireplace is upright. Remove protective side packaging. Slide fireplace out of carton. Remove protective plastic wrap. Hold the screen lift and pull forward. Remove log set by cutting plastic ties. Carefully unwrap log. Check for any shipping damage.
  • Page 7: Air For Combustion And Ventilation

    AIR FOR COMBUSTION AND VENTILATION WARNING : This heater shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home. PRODUCING ADEQUATE VENTILATION The following are excerpts from National Fuel Gas Code, NFPA 54/ ANSI Z 223.1,Section 5.3, Air for Combustion and Ventilation.
  • Page 8 Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support. (volume of space) ÷ 50 cu. ft. = (Maximum Btu/Hr the space can support) Example: 2560 cu. ft. (volume of space) ÷50 cu. ft . = 51.2 or 51,200(maximum Btu/Hr the space can support) Add the Btu/Hr of all fuel burning appliances in the space.
  • Page 9: Installation

    Ventilation Air From Outdoors Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent " openings: one within 12 of the ceiling and one " within 12 of the floor. Connect these items directly to the outdoors or spaces open to the outdoors.
  • Page 10 Minimum Wall and Ceiling Clearances (see Figure 4) Clearances from outermost point of fireplace to any combustible side wall should not be less than 12 inches. Clearances from the fireplace to the ceiling should not be less than 48 inches. Figure 4 –...
  • Page 11 The installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11 and 14 inches of water column for propane and between 5 and 10.5 inches of water column for natural gas.
  • Page 12 CAUTION: Two gas line installations at the same time is forbidden. Do not open cover while the heater is running. Heater is pre-set at factory for propane gas, no changes are required for connecting to propane. Only a qualified installer or service technician can perform gas selection and connecting to gas supply. For changing from propane to natural gas supply Remove bottom screw from cover plate, see figure 8, and rotate to expose gas selection valve.
  • Page 13 CHECKING GAS CONNECTIONS WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks immediately. Pressure Testing Gas Supply Piping System Test Pressures In Excess Of ½ PSIG(3.5kPa) Disconnect heater with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system.
  • Page 14 Figure 12 – Checking Gas Joints INSTALLING LOGS WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no flame comes in contact with any log.
  • Page 15: Operating Heater

    STEP 5: Insert the pinhole on the upper part of STEP 4: Insert the pinhole on the upper log 5 in the pin on log 2. Place the pin hole on part of log 4 in the pin on log 1. Place the the lower part of log 5 in the pin on log 3.
  • Page 16 LIGHTING INSTRUCTIONS STOP! Read the safety information on page 3. Unscrew ignitor cap and install a AAA type battery with its anode (“+”) pointing out. Replace cap Make sure equipment shutoff valve is fully open. Warning: You must operate this fireplace with the fireplace screen in place. Make sure fireplace screen is installed before running fireplace.
  • Page 17 MANUAL LIGHTING PROCEDURE (Match Light) Remove screen by lifting and pulling forward. Follow steps 1 through 7 under MANUAL OPERATING Lighting Instructions. With Control Knob in PILOT position, strike match, and hold near pilot. Press in Control Knob; pilot should light.
  • Page 18: Cleaning & Maintenance

    CLEANING AND MAINTENANCE WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shook or personal injury. Turn off heater and let cool before cleaning. WARNING: Failure to keep primary air openings of burners clean may result in sooting and property damage.
  • Page 19: Troubleshooting

    CABINET Air Passageways · Use a vacuum cleaner or pressurized air to clean. Exterior · Use a soft cloth dampened with a mild soap and water mixture. Wipe the cabinet to remove dust. LOGS · If you remove logs for cleaning, refer to Installing Logs (page 14) to properly replace logs. ·...
  • Page 20 OBSERVED REMEDY POSSIBLE CAUSE PROBLEM igniting operation until air is removed. 4. ODS/pilot is clogged. Clean ODS/pilot (see Cleaning and Maintenance Page 18) or replace ODS/pilot assembly. 5. Incorrect inlet gas pressure or inlet Check inlet gas pressure or replace regulator is damaged.
  • Page 21 OBSERVED REMEDY POSSIBLE CAUSE PROBLEM Heater produces 1. Turning control knob to HIGH (5) position 1. Turn control knob to LOW (1) position a whistling noise when burner is cold. and let warm up for a minute. when burner is lit. 2.
  • Page 22: Replacement Parts

    P.O. Box 192, Rt. 22 West Contact authorized dealers of this MillCreek, PA 17060 product. If they can’t supply original replacement part(s) call KOZY WORLD KOZY-WORLD PHONE PHONE NUMBER (814)643-1775 NUMBER:(814)643-1775 for referral information. http://www.worldmkting.com When calling KOZY WORLD, have ready...
  • Page 23 PARTS LIST GFD2921 & GFDC3029 & GFD2915 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 22 of this manual. KEY NO PART NUMBER DESCRIPTION QUANTITY SIT545-200 T-STAT VALVE...
  • Page 24 PARTS LIST GFD2921 & GFD2915 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 22 of this manual.
  • Page 25 PARTS LIST GFDC3029 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 22 of this manual.
  • Page 26: Installation Instructions For Corner Surround And Hearth

    INSTALLATION INSTRUCTIONS For CORNER SURROUND AND HEARTH READ INSTRUCTIONS BEFORE BEGINNING INSTALLATION. Check to see that you have the following. If any part or parts are missing, contact the dealer where you bought the surround and hearth. TOOLS REQUIRED: Measuring Tape, Pencil, Level, #2 Phillips Screw Driver, Hammer, Electric Drill, 5/6" Drill Bit, Hand or Electric Saw INSTALLATION: 1.
  • Page 27 6. Place the assembled fireplace on the middle where it is 27” from the corner and form a 45 degree angle to each side wall. Move the assembled surround to the corner, with side panels close to side walls. Move the fireplace to where it can properly attach the surround.

This manual is also suitable for:

Gfd2921Gfdc3029
