10-Bay Charger Installation
The 10-bay charging station will hold and charge 10 batteries from zero to full within five
hours. The CRA-A175 charger kit will come with two 5-bay chargers, a splitter cable adapter
and power supply.
Interlink the two, 5-bay chargers by sliding one into the other.
The split cable adapter will have one longer end. Insert
the longer end of the cable into the charger's female
port furthest from the power supply. Route the cable
through the groove on the bottom side of the charger.
10-bay charger with
vertical mount accessory
