- Page 1 IPES/IES-0008B Series 8 10/100TX (w/8 PoE at/af) Industrial Un-Managed Switch User Manual Mar. 2022...
- Page 2 Recommendation for Shielded network cables STP cables have additional shielding material that is used to reduce external interference. The shield also reduces the emission at any point in the path of the cable. Our recommendation is to deploy an STP network cable in demanding electrical environments. Examples of demanding indoor environments are where the network cable is located in parallel with electrical mains supply cables or where large inductive loads such as motors or contactors are in close vicinity to the camera or its cable.
- Page 3 Lantech Communications Global Inc. Products offered may contain software which is proprietary to Lantech Communications Global Inc. The offer or supply of these products and services does not include or infer any transfer of ownership.
- Page 4 FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.
-
Page 5: Table Of Contents
Content Chapter 1 Introduction ..........5 Model Lists ............... 5 Chapter 2 Hardware Description ......5 Physical Dimension ........5 Package Content:........... 6 IP Protection ........... 7 LED Indicators..........10 Chapter 3 Hardware Installation ......11... -
Page 6: Chapter 1 Introduction
Chapter 1 Introduction Lantech IPES/IES-0008B Series are 8 10/100 Base-TX with M12-connctor unmanaged industrial switches for IP41/IP54 rated protection, which meet the high reliability requirements demanded by industrial rolling stock applications. Model Lists Model name 10/100TX ports PoE ports Power input... -
Page 7: Package Content
2.2 Package Content: Manual CD* Product *By request... -
Page 8: Ip Protection
2.3 IP Protection The IP Code, Ingress Protection Rating, sometimes also interpreted as International Protection Rating, classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water in mechanical casings and with electrical enclosures. It is published by the International Electrotechnical Commission (IEC) Solid particle protection The first digit indicates the level of protection that the enclosure provides against access... - Page 9 Liquid ingress protection The second digit indicates the level of protection that the enclosure provides against harmful ingress of water. Protected Level Testing for Details against — — protected Dripping Dripping water (vertically Test duration: 10 minutes water falling drops) shall have no Water equivalent to 1 mm harmful effect.
- Page 10 Powerful Water projected in powerful Test duration: at least water jets jets (12.5 mm nozzle) 3 minutes against the enclosure from Water volume: 100 litres per any direction shall have no minute harmful effects. Pressure: 100 kPa at distance of 3 m Immersion Ingress of water in harmful Test duration: 30 minutes...
-
Page 11: Led Indicators
2.4 LED Indicators The diagnostic LEDs that provide real-time information of system and optional status are located on the front panel of the industrial switch. The following table provides the description of the LED status and their meanings for the switch. Color Status Meaning... -
Page 12: Chapter 3 Hardware Installation
For POE models: Do not use units POE ports to uplink to another unit. (May Cause Damage) Lantech strongly advise the installation of a Galvanic isolated DC/DC converter between the power supply and the Ethernet switch on all Non-Isolated units. Please contact the sales team for advice on which units support isolated power supply. - Page 13 PTZ or heater applications) IES-0008B-41-12V Dual 9.5~60VDC IES-0008B-41-72V Dual 50.4~90VDC Please make sure that the external power supply unit you use to provide the PoE voltage meet the following criteria: The output voltage of power supply must exceed 48VDC for 802.3af and 53VDC for 802.3at operation (with IPES-0008B-72V, only 72VDC can power both the 802.3af and 802.3at PD.) ...
- Page 14 Redundant Power Input The power input can be supported redundantly. The supply voltage is electrically isolated from the housing. 3.1.4 Fitting the device, grounding Install the system in a dry and clean area to protect the switch to get exposed with dirt. Plug the connector to the power supply plug then turn on the power supply.
- Page 15 surrounding. Pin assignment of M12 10/100Tx network connector 3.1.6 Check the status of LED, make sure the switch was in working status. Note: The protection class IP41/54 is only achieved when bolted together. The other components attaching to the system have to meet with the IP41/54 protection class in order to reach the whole system IP41/54 protection.
- Page 16 Empty ports must be sealed with the protective caps supplied.
