- Page 1 Lantech IPES-0208CA 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo w/ 8x12V/24V/48V PoE at/af Injector Industrial Switch User Manual V1.2 May 2021...
- Page 2 FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.
-
Page 3: Table Of Contents
Content Introduction ..............1 Features ..............1 Technical Specification ..........2 Package Contents ........... 5 Safety Precaution ............ 5 Hardware Description ..........6 Physical Dimension ..........6 Front Panel .............. 7 Top View ..............8 LED Indicators ............8 Ports ................. 9 Cabling .............. -
Page 4: Introduction
Introduction IPES-0208CA Industrial Switch is a cost-effective solution, which meets the high reliability requirements demanded by industrial applications, and also supports to operate in the wide temperature -40°C ~ 75°C environments(-E model). Besides, the equipment supports 12V/24V/48V DC power input and provides the PoE function with 48VDC output for any kinds of powered devices to receive power as well as data over an RJ-45 cable. -
Page 5: Technical Specification
Technical Specification The technical specifications of IPES-0208CA Industrial Switch are listed as follows. Communications Compatibility IEEE 802.3, 802.3u, 802.3ab 802.3z, 802.3x, 802.3af/at 10/100Base-T Switch Architecture Back-plane (Switching Fabric): 5.6Gbps Packet throughput ability(Full-Duplex): 8.3Mpps @64bytes Interface Connectors 10/100TX: 8 x RJ-45 10/100/1000T/ Mini-GBIC Combo: 2 x RJ-45 + 2 x 100/1000 SFP sockets LED Indicators... - Page 6 Power Input External Power Supply: DC 9~56V, Redundant power D9V~DC 56V and connective removable terminal block Fault Output 1 Relay Output Mechanism Dimensions (WxHxD) 74mm (W) x 114mm (D) x 152mm (H) Enclosure IP-30, Metal shell with solid mounting kits Mounting DIN Rail and Wall Mount** Design Protection...
- Page 7 Free Fall IEC60068-2-32 Shock IEC60068-2-27 Vibration IEC60068-2-6...
-
Page 8: Package Contents
Package Contents Please refer to the package contents list below to verify them against the checklist. IPES-0208CA Industrial Switch (with DIN-Rail Bracket) User manual (By request) Removable Terminal Block Optional Wall-mount Kit** (2 wall-mount bracket with screws) Compare the contents of the industrial switch with the standard checklist above. -
Page 9: Hardware Description
Hardware Description In this paragraph, the Industrial switch’s hardware specs, ports, cabling information, and wiring installation will be described. If this switch needs to uplink with another switch via a PoE copper port, please make sure the uplink port on the other unit is a none-PoE interface. You may also contact our sales team to confirm if the switch supports power isolation. -
Page 10: Front Panel
Front Panel The Front Panel of IPES-0208CA Industrial Switch is shown below Figure-2 Figure-2: Front Panel of the PoE Injectors Industrial Switch... -
Page 11: Top View
Top View The top view of IPES-0208CA Industrial Switch has one terminal block connector of two DC power inputs and Relay circuit contact. Please refer to Figure-3 for further information. Figure-3: Top View of the PoE Injectors Industrial Switch LED Indicators The diagnostic LEDs located on the front panel of the industrial switch provide real-time information of system and operation status. -
Page 12: Ports
(RJ-45) Flashing Networking is active Not connected to network Connected to network at speed of 100Mbps Green Connected to network at speed of 10Mbps or not connected to network Table-1: LED Indication Definition Ports RJ-45 ports The Fast Ethernet ports (RJ-45) will auto-sense for 10Base-T or 100Base-TX connections. -
Page 13: Cabling
MDI-X Signal MDI Signal Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-) Transmit Data plus (TD+) Receive Data plus (RD+) Transmit Data minus (TD-) Receive Data minus (RD-) Table-3: MDI/MDI-X Port Pin-outs The following figures show the cable schematic for straight-through type (Figure-4) and crossover type (Figure-5). -
Page 14: Wiring The Power Inputs
Wiring the Power Inputs Please follow the steps below to wire the power cord which from the other compliant external DC power supplier. Insert the positive and negative wires into the PWR1 (V+, V-) and PWR2 (V+, V-) contacts on the terminal block connector as shown in Figure-6. Figure-6: Terminal Block Front View for Power1 &... - Page 15 Power Restriction (under - 48VDC power) IPES-0208CA only can support one -48VDC power source. If using two -48VDC power source, IPES-0208CA may cause damage.
-
Page 16: Wiring The Fault Alarm Contact
Wiring the Fault Alarm Contact The fault alarm contact is in the middle of terminal block connector as the picture shows below. Inserting the wires, will detect the fault status including power failure or port link failure (managed industrial switch only) and from a Normally Close circuit. Please refer to Figure-8 for the fault alarm contact, and Figure-9 shows the application example for the fault alarm operation. -
Page 17: Mounting Installation
Mounting Installation DIN-Rail Mounting The DIN-Rail bracket is screwed on the switch on the production line in the factory. If the bracket is not screwed on the switch, please refer to Figure-10 to screw it on the switch. Follow the steps below to hang the industrial switch. Figure-10: Rear side of the PoE Injectors Industrial Switch Use the screws to screw the DIN-Rail bracket on the rear side of the industrial switch. -
Page 18: Wall Mounting
Figure-11 Then, lightly pull-down the bracket into the rail as shown in Figure-12. Figure-12 Check if the bracket is tightened on the rail or not. To remove the switch from the rail, reverse steps above. Wall Mounting**(optional) Please refer to Figure-13 and follow the steps below to mount the industrial switch with... - Page 19 wall-mount bracket, and the detail dimension of the bracket as Figure-14. 1. Remove the DIN-Rail bracket from the switch; loose the screws to remove it. 2. Place the wall-mount bracket on the top side and bottom side of the switch. 3.
-
Page 20: Hardware Installation
Hardware Installation In this paragraph, we are going to explain how to install IPES-0208CA Industrial Switch and the installation points to be attended to it. Installation Steps 1. Unpack the Industrial switch packing. 2. Check if the DIN-Rail bracket is screwed on the Industrial switch or not. If the bracket is not screwed on the Industrial switch, please refer to DIN-Rail Mounting section for DIN-Rail installation. -
Page 21: Network Application
Network Application This segment provides the sample to help user have more actual idea of industrial switch application. For a sample application of the industrial switch, see the Figure-15 below. IPES-0208CA-12V Industrial Switch Figure-15: Network Application... -
Page 22: Troubleshooting
Troubleshooting Verify that you are using the right power cord/supplier/adapter (DC 12V/48V), please don’t use the power supplier/adapter with a non-compliant DC output voltage, or it will burn the equipment. Select the proper UTP/STP cable to construct your network. Please check that you are using the right cable.
