Roger Access Control System
Installation guide for
HRT82MF-CH card holder
Firmware version: 1.0.2.16 or newer
Hardware version: 1.0
Document version: Rev. D
© 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at
the
www.roger.pl
website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roger HRT82MF-CH
Summary of Contents for Roger HRT82MF-CH
- Page 1 Hardware version: 1.0 Document version: Rev. D © 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at www.roger.pl website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).
-
Page 2: Description And Specification
Functional description of HRC series controllers Installation guide for HRC series controllers In order to acquire the first one it is necessary to obtain Roger consent and sign non-disclosure agreement (NDA). The second one is available at www.roger.pl. -
Page 3: Installation
HRT82MF-CH Installation Guide.doc 2018-09-21 3. I NSTALLATION 3.1 Terminals and connection diagram Fig. 1 HRT82MF-CH card holder Table 2. HRT82MF-CH terminals Term. Description Term. Description 12VDC power supply RACS CLK/DTA bus Ground RACS CLK/DTA bus not used Tamper not used Tamper Fig. -
Page 4: Power Supply
GND terminals. Additionally, the GND terminal is used as reference potential for the RACS CLK/DTA bus. HRT82MF-CH power supply can be provided by connection to buffer power supply unit (e.g. PS-15DR, PS20) or connection to AUX output of HRC402DR controller (see fig. 2). Backup battery connected to power supply unit or directly to HRC402DR controller can be used in order to ensure operation in case of 230VAC power failure. - Page 5 HRT82MF-CH Installation Guide.doc 2018-09-21 Damages resulting from improper maintenance or use are not covered by warranty Fig.4 HRT82MF-CH latches and surface mounting 5/11...
- Page 6 HRT82MF-CH Installation Guide.doc 2018-09-21 Fig.5 HRT82MF-CH-F flush mounting 6/11...
-
Page 7: Device Programming
4. C ONFIGURATION 4.1 Device programming The address of factory new HRT82MF-CH is ID=0 and such device is ready to communicate with HRC series controller requiring no additional configuration. If necessary, HRT82MF-CH settings can be modified with RogerVDM software (available at www.roger.pl) after connection to RUD-1 communication interface. - Page 8 HRT82MF-CH Installation Guide.doc 2018-09-21 Fig. 7 Device select window in RogerVDM software Fig. 8 Configuration window in RogerVDM software Table 3. Configuration parameters Parameter Values Description General Device Name 16 ASCII Device description which can be filled with any comment by...
-
Page 9: Firmware Update
Six bytes key used for reading MSN or SSN. FFFFFFFFFFFF 4.2 Firmware update HRT82MF-CH firmware can be updated with RogerVDM (available at www.roger.pl) after connection to RUD-1 communication interface. Firmware update procedure 1. Connect device to RUD-1 communication interface according to fig. 6 2. -
Page 10: Memory Reset
Fig. 9 Firmware update window in RogerVDM software 4.3 Memory reset In order to restore HRT82MF-CH factory default settings place jumper on MEM pins and then restart the device either by placing and removing jumper on RST pins or by switching power supply off and on. -
Page 11: Ordering Information
Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
