- Page 1 PRTxxLT series EM 125 kHz readers Firmware version: n/a Document version: Rev. I This document refers to following products: PRT12LT PRT12LT-BK PRT32LT PRT42LT PRT42LT-BK PRT62LT PRT64LT PRT66LT Operating Manual...
-
Page 2: About This Manual
This manual is dedicated for all versions of PRTxxLT readers as all of them represent the same logical functionality. The only difference between various types of PRTxxLT series readers is limited to their mechanical construction, environment in which they can be installed and keypad which is available in some of PRTxxLT readers. -
Page 3: Operating Modes
Magstripe (ABA Track II emulation, also called Clock & Data) RACS address ID0..3 (addressable format for communication with Roger controllers) Wiegand Formats When using Wiegand transmission format, data is transmitted to the host via CLK and DTA lines. Depending on the selected version of the transmission format, the reader can send 26, 32, 34, 42 or 66 bits to the host. -
Page 4: Memory Reset
PRTxxLT series readers Operating Manual.doc 2019-01-29 RACS Format When using RACS format, PRTxxLT reader communicates with the access controller via CLK/DTA lines. Unlike in the Wiegand and Magstripe formats, the PRTxxLT unit using RACS format requires an individual address (ID=0…3) to be set during configuration of reader’s operating mode (Memory Reset procedure). - Page 5 3. [1]: Read 1-time programming card and then wait for two beeps 3.2.1. Reader Operating Modes The factory new reader is pre-configured with RACS address ID=0 but it can be changed using Memory Reset procedure. There are following operating modes available for the PRTxxLT series reader: Code...
- Page 6 PRTxxLT series readers Operating Manual.doc 2019-01-29 transmission format. 42 bit Wiegand 66 bit Wiegand 32 bit Wiegand, without parity Wiegand, without parity, reverse order Note: For Wiegand data formats the second digit of the operating mode code (marked as X) specifies the method which reader uses when transmitting PIN-s or keys.
- Page 7 PRTxxLT series readers Operating Manual.doc 2019-01-29 keys long 1-4 keys long PIN, each key represented by 8-bit long codes (key codes transmitted as Wiegand 32 according to table A). Reader sends data after four keys are pressed or bit stream without control earlier when # key is pressed.
- Page 8 PRTxxLT series readers Operating Manual.doc 2019-01-29 1010 1011 4 . I N S T A L L A T I O N U I D E L I N E S Reader should be installed in such a way to ensure physical access to the connection cable and/or screw terminals.
- Page 9 PRTxxLT series readers Operating Manual.doc 2019-01-29 9/17...
- Page 10 PRTxxLT series readers Operating Manual.doc 2019-01-29 10/17...
- Page 11 PRTxxLT series readers Operating Manual.doc 2019-01-29 11/17...
- Page 12 PRTxxLT series readers Operating Manual.doc 2019-01-29 12/17...
- Page 13 PRTxxLT series readers Operating Manual.doc 2019-01-29 13/17...
- Page 14 PRTxxLT series readers Operating Manual.doc 2019-01-29 14/17...
- Page 15 PRTxxLT series readers Operating Manual.doc 2019-01-29 15/17...
- Page 16 PRTxxLT series readers Operating Manual.doc 2019-01-29 Technical Specification Supply voltage Nominal 12VDC, min,/max. range 10-15 VDC Current consumption PRT12LT: 65mA (average) PRT12LT-BK: 45mA PRT32LT: 65 mA PRT42LT: 65 mA PRT42LT-BK: 45mA PRT62LT: 45mA PRT64LT: 65mA PRT66LT: 45 mA Reading distance...
- Page 17 PRTxxLT series readers Operating Manual.doc 2019-01-29 Approvals Ordering Codes PRT12LT Outdoor proximity reader with keypad, laser engraved long durability silicon rubber keypad, two function keys, dark grey ABS enclosure, pig-tail cable PRT12LT-BK The same as PRT12LT but without keypad PRT32LT...
