Roger PRT12LT Installation And Programming Manual

Prt-lt series em 125 khz access readers
Hide thumbs Also See for PRT12LT:

Advertisement

Quick Links

EM 125 kHz Access Readers
This document refers to the following products:
Installation and Programming Guide
PRT-LT Series
Firmware 1.25
Rev.G
-
PRT12LT
-
PRT12LT-BK
-
PRT32LT
-
PRT42LT
-
PRT42LT-BK
-
PRT62LT
-
PRT64LT
-
PRT66LT

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRT12LT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Roger PRT12LT

  • Page 1 PRT-LT Series EM 125 kHz Access Readers Firmware 1.25 Rev.G This document refers to the following products: PRT12LT PRT12LT-BK PRT32LT PRT42LT PRT42LT-BK PRT62LT PRT64LT PRT66LT Installation and Programming Guide...
  • Page 2 2.3. F UNCTION Some of the PRT-LT readers are equipped with two (e.g. PRT12LT) or one (PRT42LT and PRT42LT- BK) function keys: [F1]- marked with door bell icon and [F2] – marked with the light bulb icon. The function of each function keys depends on the reader’s operation mode.
  • Page 3: Operating Modes

    · Magstripe (ABA Track II emulation, also called Clock & Data) · RACS (for communication with PR series of controllers from Roger) Wiegand Formats When employing Wiegand transmission format, data is send to the host using sequences of pulses transmitted over CLK and DTA lines (which in this case are called DATA1 and DATA0).
  • Page 4 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 RACS Format When employing RACS format, the PRT-EM unit communicates with the host via CLK/DTA lines. Unlike in the Wiegand and Magstripe formats, the PRT-LT unit using RACS format requires an individual address (ID=0…3) to be set during configuration of the reader.
  • Page 5 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 3.2. P PRT-LT R ROGRAMMING THE EADERS WITHOUT EYPAD Although some PRT-LT readers are not equipped with keypad still they can be programmed manually according to the same programming procedures as readers with keypad. The difference in programming is so that instead of pressing certain keys (like you normally do when programming readers with keypad) you must emulate keys by multiple readings of the any proximity card (this card will be latter called Programming Card).
  • Page 6 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 3.2.1. Reader Operating Modes The factory new reader is pre-configured for RACS address ID=0 however whenever required it can be changed using Memory Reset procedure. There are following operation modes available for the PRT-LT series reader: Code Operating mode Description...
  • Page 7 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 PIN/keys transmission options Description Details 1-10 digits long PIN, Each key pressed is buffered in reader’s memory; with a press of a [#] transmitted in BCD format key reader transmits entire PIN code. The PIN code is transmitted as a BCD coded number.
  • Page 8 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Table A: 8-bit key coding 11110000 11100001 11010010 11000011 10110100 10100101 10010110 10000111 01111000 01101001 01011010 01001011 00111100 00101101 Table B: 4-bit key coding ASCI 0000 0001 0010 0011 0100 0101 0110 0111 1000 1001 1010...
  • Page 9 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 3.3. I NSTALLATION UIDELINES · Reader should be installed in such a way to assure physical access to the connection cable · A new factory delivered unit is configured for RACS address ID=0 however data output format can be changed whenever required using Memory Reset procedure ·...
  • Page 10 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 10 from 17...
  • Page 11 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 11 from 17...
  • Page 12 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 12 from 17...
  • Page 13 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 13 from 17...
  • Page 14 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 14 from 17...
  • Page 15 PRT-LT Series Readers fv1.25 Rev. G 2016-10-08 Page 15 from 17...
  • Page 16 PRT62LT: Class IV PRT64LT: Class IV PRT66LT: Class IV Dimensions H x W x D PRT12LT/PRT12LT-BK: 150.5 X 46 X 23 mm PRT32LT: 105 X 105 X 31 PRT42LT/PRT42LT-BK: 151.5 X 45 X 20.5 mm PRT62LT: 100 X 45 X 25 mm...
  • Page 17 Outdoor proximity reader with keypad, laser engraved long durability silicon rubber keypad, two function keys, dark grey ABS enclosure, pig-tail cable PRT12LT-BK The same as PRT12LT but without keypad PRT32LT Indoor proximity reader with keypad, light grey top/dark grey bottom, reader can...
