Summary of Contents for Roger RUD-3
- Page 1 U S B P r o x i m i t y R e a d e r / W r i t e r R U D - 3 v 1 . 0 Document version: Rev. A U s e r s M a n u a l...
- Page 2 The reader is supplied from serial USB port which is also used for communication with the device. The RUD-3 can be used as card enroll reader for access control system or any other application which requires card reader.
- Page 3 W o r k i n g w i t h P R M a s t e r p r o g r a m In the list of available readers in the PR Master 4.4.6 control program, RUD-3 readers connected to the system are displayed.
- Page 4 W o r k i n g w i t h R A R C p r o g r a m From the menu list (Options > Port) choose HID1 (RUD-3) … type device, then press OK button.
- Page 5 W o r k i n g w i t h o t h e r p r o g r a m s Support for RUD-3 reader can also be implemented in other programs, in this case, the logic of reader handling depends completely on the program’s author. For integration purposes a RUD-3 software SDK has been released.
- Page 6 Optionally, the RUD-3 can be connected to computer by other USB cable of a length not exceeding 5 meters. However any modifications of original USB cables are prohibited.
- Page 7 RUD-3 v1.0 EN Rev. A.doc 2011-08-04 Technical Data Power supply 5 VDC directly from the USB port Average current consumption 80 mA Cards ISO/IEC 14443A and Mifare proximity transponders Up to 6 cm for ISO cards (while in an optimal relative...
