Roger PRT12MF-DES Operating Manual

Hide thumbs Also See for PRT12MF-DES:
Table of Contents

Advertisement

Quick Links

Roger Access Control System
PRT12MF-DES, PRT84MF and PRT82MF readers
Operating Manual
Firmware version: v1.0.8 or newer
Hardware version: 1.0
Document version: Rev. C
This document refers to the following products:
PRT12MF-DES, PRT12MF-DES-BK, PRT82MF, PRT82MF-BK, PRT84MF and PRT84MF-BK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRT12MF-DES and is the answer not in the manual?

Questions and answers

Related Manuals for Roger PRT12MF-DES

Summary of Contents for Roger PRT12MF-DES

  • Page 1 Roger Access Control System PRT12MF-DES, PRT84MF and PRT82MF readers Operating Manual Firmware version: v1.0.8 or newer Hardware version: 1.0 Document version: Rev. C This document refers to the following products: PRT12MF-DES, PRT12MF-DES-BK, PRT82MF, PRT82MF-BK, PRT84MF and PRT84MF-BK...

  • Page 2: Table Of Contents

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Contents 1. General description ....................... 3 1.1 Introduction ........................3 1.2 Features ..........................3 1.3 Card number ........................3 1.3.1 CSN section ........................4 1.3.2 PCN section ........................4 1.3.3 RCN format rules ......................5 2.

  • Page 3: General Description

    PIN to access controller. Contrary to other PRTxxMF series readers, PRT12MF-DES readers can also read the most secure MIFARE DESFire and MIFARE Plus card in full range (both CSN and PCN). The factory new reader is pre-configured with RACS CLK/DTA operating mode and ID=0 address.

  • Page 4: Csn Section

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Note: In the examples below the letter ‘h’ signifies hexadecimal number. 1.3.1 CSN section CSN section can be a part of RCN and it is based on factory defined chip serial number of MIFARE card.

  • Page 5: Rcn Format Rules

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 defined separately for each of MIFARE Classic, Plus and Desfire formats. In case of PCN of MIFARE Ultralight, the settings of MIFARE Classic are used but the location of PCN is not configurable. Example...

  • Page 6: Operating Modes And Output Formats

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Section PCN=223344 Poz. then RCN is RCN=CSN+PCN=C4C5C6C7223344. CSN section PCN section The number returned by PRT reader with Wiegand 66 bit output format (64 data bits + 2 control bits): The number returned by PRT reader with Wiegand 42 bit output format (40 data bits + 2 control...

  • Page 7: Racs Clk/Dta Mode

    2018-08-23 2.1 RACS CLK/DTA mode RACS CLK/DTA mode is dedicated for operation of reader with Roger access controllers. In this mode the reader uses two communication lines called CLK and DTA for bidirectional transmission. Each reader configured to the RACS CLK/DTA mode must have an unique address in range from 0 to 3.

  • Page 8: Reader Configuration

    3.1 RogerVDM configuration To perform this method reader has to be connected to PC via RUD-1 interface (fig. 3) and programmed by means of RogerVDM software which is available at www.roger.pl. Fig. 3 Connection of reader to RUD-1 interface Fig. 4 Location of service contacts Connection method 1.
  • Page 9 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Connect Configuration 5. Click , the program will establish connection and will automatically display tab. 6. Depending on requirements of specific installation configure operating mode, address and other settings. Send to Device 7. Click to update the configuration of reader.
  • Page 10 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Wiegand keypad 0..6 Sets the PIN/keys transmission options output format Wiegand mode (details in table 3, chapter 3.2): 0 – The PIN code 1 to 10 digits and transmitted as a BCD number 1 - The PIN code 1 to 12 digits and transmitted as...
  • Page 11 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 upon key press 1 - Yes flash whenever key is pressed. Input types 0 – NO Defines input type. 1 – NC 0 – NO Defines input type. 1 – NC Acoustic signalization Buzzer loudness level 0..100%...
  • Page 12 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 which indicates sector where PCN number is stored (by default Roger AID number is: 5156). Block ID 0..15 Specifies block number within sector where PCN code is stored. Key type 0 - A Specifies key type used to encrypt data stored on the card.

  • Page 13: Manual Programming Of Operating Mode

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 File ID (FID) 0..32 Defines file number in which RCN is placed. For DESFire EV0 cards it is acceptable number from 0 to 16, however in EV1 cards – numbers from 0 to Communication 0 –...
  • Page 14 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 66 bit Wiegand 32 bit Wiegand, no parity 32 bit Wiegand, reverse order, no parity The third digit of the operating mode code (marked by “x”) specifies the method which reader applies when transmitting PIN or key. For details regarding methods of PIN transmission refer to table 3.
  • Page 15 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Each pressed Each key pressed is immediately transmitted to the host transmitted separately controller as a sequence of 8 bits (XXXXXXXX) where 8-bit number XXXXXXXX represents code pressed without parity bits supplemented by two control bits (E and P). The E represents...

  • Page 16: Memory Reset

     It is recommended to install PRT82MF reader on a flush type box 60mm diameter.  PRT12MF-DES reader is delivered with additional extended base panel which is intended to be used when reader is installed on metal surface and/or if there is a need for extra space for connection wires.
  • Page 17 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Fig. 6 PRT82MF/PRT84MF enclosure disassembly Table 4: Connection wires Name Wire colour Description Supply plus Blue Supply minus Green RACS CLK/DTA communication line CLK Brown RACS CLK/DTA communication line DTA Yellow IN1 input Pink...
  • Page 18 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Fig. 7 Dimensions and tamper details, standard (low profile) bottom enclosure 18/23...
  • Page 19 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Fig. 8 Dimensions and tamper details, standard (high profile) bottom enclosure 19/23...

  • Page 20: Firmware Update

    5. F IRMWARE UPDATE Firmware can be updated by means of RogerVDM software and RUD-1 communication interface. The file with latest firmware is available at www.roger.pl. Firmware update procedure: 1. Connect reader to RUD-1 interface according to fig. 3. 2. Put jumper on FDM contacts (fig. 4).

  • Page 21: Technical Specification

    PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 Fig. 10 Firmware Update window view. 6. T ECHNICAL SPECIFICATION Table 5. Technical specification Supply voltage Nominal 12VDC, min./max. range 10-15VDC Current consumption (average) PRT12MF-DES: ~70 mA PRT12MF-DES-BK: ~50 mA PRT82MF: ~60 mA PRT82MF-BK:...

  • Page 22: Ordering

    PRT12MF-DES: Class IV PRT82MF/PRT84MF: Class II Dimensions H x W x D and weight PRT12MF-DES: 152,5 x 46 x 23(35) mm; 150g PRT82MF: 85 x 85 x 22 mm; 100g PRT84MF: 130 x 45 x 22 mm; 100g Certificates 7. O RDERING Table 6.
  • Page 23 PRT12MF-DES PRT82MF PRT84MF Operating Manual.doc 2018-08-23 This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health. The user is obliged to deliver equipment to the designated collection points of electric and electronic waste.
