SYSTEM SPECIFICATIONS

Model
Maximum sound output
(Short term sine wave output on axis in half space,
averaged 100-3000 Hz @ 1 m)
Frequency range (-3 dB)
Crossover frequency
Bass driver (magnetically shielded)
Treble driver (magnetically shielded)
Amplifier short term power (Bass + Treble)*
Signal input connectors
Input impedance
Level control: Output level with three position
toggle switch @ 0 dBu input
Bass level control, operating range in 2 dB steps
Tabletop EQ control
Bass EQ control
Mains voltage
Power consumption
Standby / Idle / Full output
Weight
Dimensions
*Long term output power is limited by driver unit protection circuit
Genelec Oy M030
d
B
r
90
A
85
TABLETOP EQ
90 80
85
80
BASS LEVEL
90
85
BASS EQ
80
20 50 100 200
Figure 4. The curves show the effect of the "Bass
Level", "Tabletop EQ" and "Bass EQ" controls on the
free field response of the M030.
(dBr) vs freq (Hz) 27 May 2013
500 5k
1k 2k 10k
Hz
M030
105 dB SPL
58 Hz – 21 kHz
3 kHz
130 mm (5")
19 mm (¾")
80 W + 50 W
Balanced XLR / 1/4" TRS phone jack combination
106 dB SPL (0 dB), 96 dB SPL (-10 dB), 86 dB SPL (-20 dB)
-3 dB @ 230 Hz
Automatic selection 100 - 230 V (In Japan 100V only)
<0.5 W / 8.5 W / 40 W
4.9 kg (10.8 lbs)
273 x 190 x 190 mm
(10¾ x 7½ x 7½")
Genelec Oy M040
d
B
r
90
A
85
90 80
85
80
90
85
80
20k
20 50
Figure 5. The curves show the effect of the "Bass Lev-
el", "Tabletop EQ" and "Bass EQ" controls on the free
field response of the M040.
M040
107 dB SPL
48 Hz – 20 kHz
2.5 kHz
165 mm (6.5")
25 mm (1")
80 W + 50 W
Unbalanced RCA
10 kOhm
0, -2, -4 dB @ 100 Hz
-3 dB @ 210 Hz
-2 dB @ 80 Hz
<0.5 W / 10 W / 60 W
7.4 kg (15.4 lbs)
337 x 235 x 229 mm
(13¼ x 9¼ x 9")
(dBr) vs freq (Hz) 27 May 2013
TABLETOP EQ
BASS LEVEL
BASS EQ
100
200 500 1k 2k
20k
5k 10k
Hz
