Genelec M040 Quick Setup Manual page 5

Loudspeaker Mounting Position
Flat anechoic response
Free standing in a damped room
Free standing in a reverberant room
Near the listener on a table or other reflective surface
In a corner
Table 1. Suggested tone control settings in some typical situations
h
M030
h
175 mm
6 7/8 in
Figure 1. The location of the
acoustic axis
Once the connections have been made, the loud-
speakers can be switched on.
ISS™ -function
Both loudspeaker models have a power switch on
the back panel. Set this switch to the "OFF" position
when the loudspeakers are left unused for several
days or when connecting or disconnecting any ca-
bles in the system.
When the power switch is set to "ON", the ISS™
Intelligent Signal Sensing function powers the loud-
speakers up when playback begins. The mode in-
dicator light on the loudspeaker lights up and the
playback resumes after a slight delay (<2 seconds).
ACOUSTIC
AXIS
Against a wall
M040
210 mm
8 1/4 in
Figure 2. Connectors and controls on the back panel
Bass Level
Free space
-2 dB
-4 dB
-2 dB
-4 dB
BASS
POWER
LEVEL
SWITCH
SWITCH
ON OFF
Bass level
Free
-2 dB -4 dB
space
Bass EQ
Corner
-2 dB
50 Hz - 200 Hz
SIGNAL INPUTS
MAINS INPUT
ISS powers down the loudspeakers after the play-
back has ended and the loudspeakers go to stand-
by mode. The power consumption in the standby
mode is less than 0.5 watts.
Setting the playback level
The playback level of the M030 and M040 can be
matched to the output of the signal source by using
the "Level" toggle switch on the back panel. Three
settings are available. Select the one that gives the
desired playback level and good resolution of the vol-
ume control.
Bass EQ Tabletop EQ
OFF OFF
OFF OFF
OFF OFF
OFF ON
ON OFF
EQ
LEVEL
SWITCH
SWITCH
EQ Level
OFF Tabletop EQ
Low High Very low
-10 dB 0 dB -20 dB
