SYSTEM SPECIFICATIONS

Lower cut-off frequency, –6 dB:
_____________________________________________
Upper cut-off frequency, –6 dB:
_____________________________________________
Accuracy of frequency response:
_____________________________________________
Maximum short term sine wave acoustic output on axis in half
space, averaged from 100 Hz to 3 kHz:
_____________________________________________
Maximum long term RMS acoustic output in same conditions
with IEC weighted noise (limited by driver unit protection
circuit):
_____________________________________________
Maximum peak acoustic output per pair,
at 1 m distance with music material:
_____________________________________________
Self generated noise level in free field at 1 m on axis:
_____________________________________________
Harmonic distortion at 85 dB SPL at 1 m on axis:
Freq:
_____________________________________________
Drivers: Bass
Treble
Both drivers are magnetically shielded
_____________________________________________
Weight:
_____________________________________________
Dimensions: Height
(including Iso-Pod™ table stand)
Height
(without Iso-Pod™ table stand)
Width
Depth
< 56 Hz
> 25 kHz
62 Hz – 20 kHz (± 2.5 dB)
at 1 m > 100 dB SPL
at 1 m > 93 dB SPL
> 107 dB
< 5 dB (A-weighted)
50...200 Hz < 3 %
>200 Hz < 0.5 %
105 mm (4 in) cone
19 mm ( / in) metal dome
3
4
3.2 kg (7.0 lb)
242 mm (9 / in)
1
2
230 mm (9 / in)
1
16
151 mm (6 in)
142 mm (5 / in)
5
8

CROSSOVER SECTION

Input connector: Input: XLR female, balanced 10 kOhm,
_____________________________________________
Input level for 100 dB SPL output at 1 m:
_____________________________________________
Sensitivity control range relative to max output:
_____________________________________________
Crossover frequency, Bass/Treble:
_____________________________________________
Treble tilt control operating range:
_____________________________________________
Desktop 200 Hz control:
_____________________________________________
Bass roll-off control:
_____________________________________________
Bass tilt control operating range in –2 dB steps:
_____________________________________________
The 'CAL' position is with all tone controls set to 'off' and
the input sensitivity control to maximum (fully clockwise).

AMPLIFIER SECTION

Bass amplifier output power:
Treble amplifier output power:
Long term output power is limited by driver unit protection
circuitry.
_____________________________________________
Amplifier system distortion at nominal output:
THD
_____________________________________________
Mains voltage:
Voltage operating range:
Power consumption:
pin 1 gnd, pin 2 +, pin 3 -
-6 dBu at volume control max
-12 dB (constantly variable)
3.0 kHz
0 to –2 dB at 15 kHz
-4 dB at 200 Hz
-4 dB at 65 Hz
0 to –6 dB at 100 Hz
50 W
50 W
< 0.05 %
100-240 V AC, 50-60 Hz
±10 %
Idle 3 W
Standby <0.5 W
Full output 60 W
