accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help
• Modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment
under FCC rules.

SYSTEM SPECIFICATIONS

Lower cut-off frequency, –6 dB
Upper cut-off frequency, –6 dB
Accuracy of frequency response, ± 1.5 dB
Maximum short term sine wave acoustic output on axis in half space, averaged from
100 Hz to 3 kHz at 1 m
Maximum long term RMS acoustic output in the same conditions with IEC weighted
noise (limited by driver protection circuit) at 1 m
Maximum peak acoustic output per pair in a listening room with music material at 1 m
Self generated noise level in free space at 1 m on axis (A-weighted)
Harmonic distortion at 90 dB SPL at 1 m on axis
Freq: 50...100 Hz
> 100 Hz
Drivers
Bass
Treble
All drivers are magnetically shielded
Weight
Dimensions
Height
Width
Depth
Height with Iso-Pod™
Figure 10. The curves above show the horizontal directivity
characteristics of the 8340A.
Figure 11. The curves above show the vertical directivity
characteristics of the 8340A.
8340A
< 38 Hz
> 22 kHz
45 Hz – 20 kHz
≥ 110 dB SPL
100 dB SPL
≥ 118 dB
≤ 5 dB
< 2 %
< 0.5 %
165 mm (6 / in) cone
1
2
19 mm ( / in) metal dome
3
4
8.4 kg (18.5 lb)
350 mm (13 / in)
13
16
237 mm (9 / in)
3
8
223 mm (8 / in)
13
16
365 mm (14 / in)
3
8
