Simrad CS94 Installation Manual page 171

a Locate the hand crank inside the Motor Control Unit.
b Remove the hand crank from its storage position.
c Remove the plastic plug on the top cover of the hull unit.
d Mount the hand crank onto the stub shaft through the hole in the top cover.
e Use the hand crank to lower the transducer.
2 Do a thorough visual inspection of the transducer.
Check for dents, scratches, holes or other damage to the surface.
Note
It is very important that neither this coating nor the internal parts of the transducer
are damaged during the handling, installation or cleaning. Any holes and/or
scratches in the transducer surface will allow water to penetrate the transducer. If
a leak occurs, the transducer must be replaced.
3 If you suspect damage, take a high resolution photo.
4 Contact your dealer or the Simrad support organization for advice.
5 Use the hand crank to hoist the transducer.
a Turn the crank until the transducer is fully retracted.
b Remove the hand crank from the stub shaft, and mount it in its storage position
in the Motor Control Unit.
Result
Requirements
The transducer is new, clean and free from scratches, dents or other physical
damage.
Date and signature:
Related topics
Installing the CS90 Hull Unit, page 153
