- Page 1 3304A Model Rev 0 Created Mar 26, 2014 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................ -
Page 5: Important Safety Instruction
Mandatory Information All persons operating and/or working on the 3304A, Vent Punch Set Machine, should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction. -
Page 6: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 7: Safety Equipment On The Machines
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 8: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 9: Important Notices
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. - Page 10 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
-
Page 11: Maintenance
Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 12: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 13: A Word To The End User
Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. -
Page 14: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... - Page 15 Technical Manual & Parts Lists...
- Page 16 Technical Manual & Parts Lists 3304A VENT PUNCH SET MACHINE AAC Drawing Number 9005392 Rev 0 NO QTY PART # DESCRIPTION 1289-102C COUPLING, DRIVE SHAFT 1353009 SUPPORT RAIL 1355479 ROD,STR,SST,1/2ODX13.5L 1395-KIT4 LASER ASSY,6 LINES 3304001 POST, CLOTH PLATE 3304004 PLATE, CLOTH...
- Page 17 Technical Manual & Parts Lists...
- Page 18 Technical Manual & Parts Lists 3304005 GUIDE ADJUSTABLE, LH AAC Drawing Number 3304005 Rev 0 NO QTY PART # DESCRIPTION 011-037 SPROCKET,18TH, MOD 011-039 SPROCKET,DRIVE,18TH 3304003 BRKT, SUPPORT 3304007 BRKT,GUIDE,LH 3304008 BRKT,CYL,LH 3304011 BRKT,GUIDE,RH 3304012 BRKT,CYL,RH 3304026 SHAFT, ADJUSTMENT KNOB 3304038 BRKT, BASE 33006102...
- Page 19 Technical Manual & Parts Lists...
- Page 20 Technical Manual & Parts Lists 3304010 TABLE ASSY. AAC Drawing Number 3304010 Rev 0 NO QTY PART # DESCRIPTION 1338-024 PANEL, PNEUMATIC 1453055 BRKT,TOGGLE VALVE 3304015 TUBE,CRS,11GA,1X2X29L 3304022 TUBE,CRS,11GA,1X2X44.13 3304035 TABLE,TOP 3304036 COUNTER ASSY AA198-5102 REGULATOR W/GAUGE & NUT AAEVR51-C07B MODULE, 2 HAND CONTROL AAQME-4-8 QUICK MALL ELBOW, 1/4 T AAQME-5-8...
- Page 21 Technical Manual & Parts Lists 1395-KIT4 LASER ASSY., 6 LINES AAC Drawing Number 9005393 PART # DESCRIPTION 1320931C LASER,LINE,MOD. 1334379 ROD, SS 1/2 OD X 14.0 LG 1395137 COLLAR, SET, THIN, .46 ID 1395148 DRILL TEMPLATE 3304031 HOLDER, LASER ROD CROSS BLOCK SSBC98032 10-32 X 1/2 BUTTON CAP SC SSSC98040...
- Page 22 1395-KIT4 LASER ASSY., 6 LINES AAC Drawing Number 9005393 Rev 0 PART # DESCRIPTION 3304A-WD DI AGRAM, WI RI NG 3800P-C17B CABLE, COUNTER 23692 STAND,3304A ELEC COUNTER 3304037 BOX,3304A ELEC CNTR 3304040 PLUG, COUNTER EEE5024C0408 COUNTER, TOTALI ZER, LCD *4FT FF36F041WA CABLE,4 COND,22 AWG...
- Page 23 Technical Manual & Parts Lists 3304A-PD PNEUMATIC DIAGRAM AAC Drawing Number 125975C Rev 0...
- Page 24 Technical Manual & Parts Lists...
- Page 25 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 26 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
- Page 27 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 Printed in the USA www.atlatt.com...
