Model 443B02
MODULAR AC LINE POWER SUPPLY
Installation and Operating Manual
This manual contains the 441A101, 441A33, 443B102 installation and operating manuals that
comprise a Model 443B02 MODULAR AC LINE POWER SUPPLY kit.
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 443B02 and is the answer not in the manual?

Questions and answers

Related Manuals for PCB Piezotronics 443B02

Summary of Contents for PCB Piezotronics 443B02

  • Page 1 MODULAR AC LINE POWER SUPPLY Installation and Operating Manual This manual contains the 441A101, 441A33, 443B102 installation and operating manuals that comprise a Model 443B02 MODULAR AC LINE POWER SUPPLY kit. For assistance with the operation of this product, contact the PCB Piezotronics, Inc.
  • Page 2  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 6 Model 441A101 MODULAR AC LINE POWER SUPPLY Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
  • Page 7  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 8 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 9 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 10 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 11 CHASSIS AND POWER SUPPLY CHASSIS: MODELS 441A33, 441A35, 441A42, 441A43, 441A45 AND 441A49 ................2 EQUIPMENT RATINGS ................................2 MULTIPLE CHASSIS CONFIGURATION ............................2 CHANGING THE FUSE ................................2 DISABLING COOLING FAN ................................ 2 AVAILABLE MODULES ................................... 2 AC POWER SUPPLY: MODEL 441A101 ............................3 DC POWER SUPPLY: MODEL 441A102 ............................
  • Page 12 CHASSIS AND POWER SUPPLY portion of the backplane labeled RAD1 and RAD0, as shown Chassis: Models 441A33, 441A35, on Figure 1 in Appendix A. The settings are as follows: 441A42, 441A43, 441A45 and 441A49 RAD1 RAD0 The PCB Series 440 Modular Chassis is the enclosure into Rack 1 which the modules of the PCB Modular Signal Rack 2...
  • Page 13 CHASSIS AND POWER SUPPLY  for all modules. CE mandates that these totals must be < 30 Model 442A102: Single-channel, line powered  watts. sensor signal conditioner, unity gain.   Model 442A103: Single-channel, line powered ICP Operation sensor signal conditioner, with gain of x1, x10, x100. ...
  • Page 14 CHASSIS AND POWER SUPPLY Appendix A: Figures Manual 19680 Rev. C ECN 50523...
  • Page 15 CHASSIS AND POWER SUPPLY Manual 19680 Rev. C ECN 50523...
  • Page 16 Model 443B102 Dual Mode Modular Signal Conditioner Card Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
  • Page 17  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 18 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 19 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 20 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.

  • Page 21: Table Of Contents

    DUAL-MODE AMPLIFIER 443B101/443B102 BEFORE OPERATING ................................2 ELECTROSTATIC DISCHARGE ................................. 2 EQUIPMENT RATINGS .................................. 2 GROUNDING ....................................2 EQUIPMENT OVERVIEW ................................2 COMPONENTS AND FEATURES ............................... 2 INPUT ......................................2 LOW PASS FILTERS ..................................3 INTEGRATOR AMPLIFIERS ................................3 OUTPUT AMPLIFIER ..................................3 OVERLOAD DETECTOR .................................

  • Page 22: Before Operating

    443B101/443B102 the housing of the transducer is isolated from Before Operating grounded measurement sources. Electrostatic Discharge If the measurement set-up is mounted in a metal High voltage electrostatic discharge instrumentation rack, ensure that only one of the (ESD) can damage electrical devices. instruments has its signal ground connected to the To avoid triboelectric transfer: chassis (and chassis connected to mains ground if...

  • Page 23: Low Pass Filters

    443B101/443B102 high temperature transient sensitivity are used, the Reference Oscillator high pass filter of the amplifier can be changed from 0.2 Hz to 2 Hz, reducing the influence from The Model 443B has a built-in reference signal temperature-induced signals. The overall gain of the source, providing a signal of 100 pC RMS at 159.2 Hz amplifier is the ratio of the output sensitivity to the ®...

  • Page 24: Setting The Output Sensitivity

    443B101/443B102 by pressing the right-facing arrow. Time Constant is >100,000 sec Press the MENU button again and the cursor is now in the sensor sensitivity position. depending on the gain selected. And then: Enter sensitivity selected accelerometer using the keys with up and down Autozero in Progress arrows.

  • Page 25: Zeroing The Output In Long Time Constant Mode (443B102 Only)

    443B101/443B102 8. Long TC may be selected in ICP® mode, so that the amplifier is DC coupled. When long TC is TEDS Features selected, the LCD will display: The 443B incorporates several features which allow Adjust DC Offset the use of sensors with TEDS electronics. The 443B X.XXXX V can read the raw data from any TEDS sensor, and is able to locally decode the data from sensors using...

  • Page 26: Displacement Measurement

    443B101/443B102 SEN TED MEM 6. Set the desired output sensitivity and press the MODE LPF LCD MENU button. The Model 443B is now set up and calibrated for displacement measurements. Using down and right arrow keys, select LF. Press the MENU button. Using the Setup Memory Press the down arrow key until the display shows:...

  • Page 27: Appendix A: Rs-232 Control

    443B101/443B102 Appendix A: RS-232 Control For RS-232 communication, the port settings should be as follows: General RS-232, DCE interface, XON/XOFF flow control, Asynchronous protocol Baud Rate 9600 Baud Start Bits Data Bits Parity None Stop Bits The message format is as follows: Start Destination Command...
  • Page 28 443B101/443B102 Start Reason Checksum Byte (0x15) Byte Byte (0x02) (0x030 The Format of a NAK Message Reason Description Byte ‘C’ Check sum error in message received from external host. ‘D’ Data overflow error – the size of the data field was larger than the message buffer.

  • Page 29: Command Set

    443B101/443B102 Command Set This list of commands is the currently supported set that is applicable to the 443B101 and 443B102 Dual Mode Amplifier modules. Command: MMOD Purpose: This command returns the module type of the card at the location specified by the command.
  • Page 30 443B101/443B102 Command: SVER Purpose: This command returns the software version number of the firmware in the target module. Response: The response string is 5 ASCII printable characters that correspond to the software version number of the module at the location specified by the command. Command Attribute: This command is supported by all modules using the protocol defined for the 441 series racks (it is a common or “CMM”...
  • Page 31 443B101/443B102 Command: SER# Purpose: Returns the serial number of the card at the target location. Response: The response string is 6 ASCII printable characters that correspond to the serial number of the module at the location sent by the command. Command String: XYCMMSER# Description:...
  • Page 32 443B101/443B102 Command: OUTS Purpose: Sets the output sensitivity of the amplifier. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYCOZOUTSXX.XX Description: X— Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 33 443B101/443B102 Command: XDCR Purpose: Sets the transducer sensitivity of the amplifier. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYCOZXDCRXX.XX Description: X— Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 34 443B101/443B102 Command: CHRG Purpose: Puts the amplifier into charge mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZCHRG Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 35 443B101/443B102 Command: ICPM Purpose: Puts the amplifier into ICP mode and sets the constant current. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZICPMZZ Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 36 443B101/443B102 Command: SETF Purpose: Sets the cutoff frequency of the low pass filter. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZSETFZ Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 37 443B101/443B102 Command: LOWF Purpose: Sets the low frequency response of the amplifier. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZLOWFZ Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 38 443B101/443B102 Command: INTG Purpose: Engages the internal integration circuitry. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZINTGZ Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 39 443B101/443B102 Command: INTU Purpose: Sets the integration units used (SI or English). Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZINTUZ Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 40 443B101/443B102 Command: REF1 Purpose: Turns on the internal sinusoidal reference oscillator. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZREF1 Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 41 443B101/443B102 Command: REF0 Purpose: Turns off the internal sinusoidal reference oscillator. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZREF0 Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 42 443B101/443B102 Command: ZERO Purpose: Zeros the output of a 443B102 when in long time constant charge mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC02ZERO Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 43 443B101/443B102 Command: ZLCK Purpose: Clamps the output of a 443B102 when in long time constant charge mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC02ZLCK Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 44 443B101/443B102 Command: NULL Purpose: Initiates the automated drift nulling routine when in long time constant charge mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC02NULL Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 45 443B101/443B102 Command: TERM Purpose: Terminates the automated drift nulling routine when in long time constant charge mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC02TERM Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 46 443B101/443B102 Command: OFFS Purpose: Sets the dc offset of the amplifier when in ICP long time time constant mode. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYCO2OFFSXX.XXX Description: X—...
  • Page 47 443B101/443B102 Command: OFF? Purpose: Returns the dc offset of the amplifier when in ICP long time time constant mode. Response: The module responds with the 6 character dc offset voltage. Command String: XYCO2OFF? Description: X— Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 48 443B101/443B102 Command: STAT Purpose: Returns the settings of the 443B. Response: The module responds with a string of the various settings delimited with semicolons. Command String: XYCOZSTAT Description: X— Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 49 443B101/443B102 using English units in integration mode. XX.XX pC/m/s^2 Transducer sensitivity for a charge sensor using SI units in integration mode. Low Frequency Response 0.2 Hz Low frequency response 0.2 Hz. 2.0 Hz Low frequency response 2.0 Hz. Med TC Medium time constant .
  • Page 50 443B101/443B102 Ref Off;OV=1;Fault=0;” The 443B102 in rack 0, slot 2 is setup as follows: ICP mode with a constant current of 2 mA, output sensitivity is 10.00 mV/unit, transducer sensitivity is 1.023 mV/unit, low frequency response is 2.0 Hz, low pass filter set to 10 kHz, integration units are SI, the internal reference is off, the unit is not overloaded, and there is no fault condition detected.
  • Page 51 443B101/443B102 Command: TEDR Purpose: Returns data stored in the TEDS sensor. Note: For sensors programmed with “Accelerometer, transfer function v0.91” (UTID 116225), use MTED in conjunction with TEDR to retrieve all of the stored data. Response: The module responds with a string of data delimited with semicolons. Command String: XYCOZTEDR Description:...
  • Page 52 443B101/443B102 Command: MTED Purpose: Returns more data stored in the TEDS sensor . Note: Sensors programmed with the “Accelerometer, transfer function v0.91” template (UTID 116225) contain more data than can be returned by the TEDR command so MTED must be used also to retrieve all of the stored data. Response: The module responds with a string of data delimited with semicolons.
  • Page 53 443B101/443B102 Command: TEDD Purpose: Returns raw hex data stored in the TEDS device. Response: The module responds with the CRC followed by a 32 byte string of hex data. Command String: XYCOZTEDD Description: X— Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 54 443B101/443B102 Command: TED1 Purpose: Enables the auto TEDS normalization feature. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZTED1 Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 55 443B101/443B102 Command: TED0 Purpose: Disables the auto TEDS normalization feature. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZTED0 Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 56 443B101/443B102 Command: TEDU Purpose: Writes to the user data field of a TEDS sensor (13 characters maximum). Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZTEDU Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 57 443B101/443B102 Command: TMID Purpose: Writes a number (0 to 511) to the measurement position ID field of a TEDS sensor. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZTMID Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3)
  • Page 58 443B101/443B102 Command: TEDW Purpose: Writes 32 bytes of hex data to a TEDS device. Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZTEDW Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 59 443B101/443B102 Command: RDAR Purpose: Reads the 8 bytes in the application register (or application register scratchpad if unlocked) of the TEDS chip (DS2430). Response: The module responds with an 8 byte string of hex data in ASCII format. Command String: XYC0ZRDAR Description: X—Rack number of the target module (Range: ASCII printable characters, 0...
  • Page 60 443B101/443B102 Command: WRAR Purpose: Writes 8 bytes to the application register scratchpad of the TEDS chip (DS2430). Response: The module responds with a “0” to tell the calling process the command has been received. Command String: XYC0ZWRAR Description: X—Rack number of the target module (Range: ASCII printable characters, 0 through 3) Y—...
  • Page 61 443B101/443B102 Command: RDSR Purpose: Reads the Status Register byte which indicates if the application register of the TEDS chip (DS2430) has been locked or not. Response: The module responds with the Status Register byte which is 0xFF if the application register is unlocked and 0xFC if it is locked. Command String: XYC0ZRDSR Description:...
  • Page 62 443B101/443B102 Command: LKAR Purpose: Permanently copies and locks the data in the application register scratchpad of the TEDS chip (DS2430) into the application register. WARNING: The application register cannot be unlocked after this command has been sent. Response: The module responds with a “0” to tell the calling process the command has been received.

  • Page 63: Appendix B: Figures

    443B101/443B102 Appendix B: Figures Manual 19854 Rev. D ECN 50523...
  • Page 64 443B101/443B102 Manual 19854 Rev. D ECN 50523...
  • Page 65 443B101/443B102 Manual 19854 Rev. D ECN 50523...
  • Page 66 443B101/443B102 Manual 19854 Rev. D ECN 50523...
  • Page 67 443B101/443B102 Manual 19854 Rev. D ECN 50523...
  • Page 68 443B101/443B102 Manual 19854 Rev. D ECN 50523...
  • Page 69 Model Number Revision: F MODULAR SERIES POWER SUPPLY ECN #: 47122 443B102 Performance ENGLISH OPTIONAL VERSIONS Sensor Input Type(s) ICP®, Charge ICP®, Charge Optional versions have identical specifications and accessories as listed for the standard model except where noted below. More than one option may be used. Voltage Gain Increment 0.1-1000 0.1-1000...
  • Page 70 Model 441A101 MODULAR AC LINE POWER SUPPLY Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
  • Page 71  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 72 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 73 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 74 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 76 Model 441A33 3-slot chassis with computer control (for Series 440 modules) Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
  • Page 77  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 78 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 79 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 80 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 83 Model 443B102 Dual Mode Modular Signal Conditioner Card Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
  • Page 84  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 85 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 86 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 87 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 88 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. UPDATE TO NEW HANDLE AND LEXAN 51414 10.19 [258.8] 6.03 [153.3] 6.19 [157.2]...
  • Page 89 MODULAR AC LINE POWER SUPPLY Installation and Operating Manual This manual contains the 441A101, 441A33, 443B102 installation and operating manuals that comprise a Model 443B02 MODULAR AC LINE POWER SUPPLY kit. For assistance with the operation of this product, contact the PCB Piezotronics, Inc.
  • Page 90  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 91 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 92 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
