- Page 1 ASSEMBLY INSTRUCTIONS : DELAN TABLE 42 X 84 Description : T-4284 Item No. ITEM NO.: T-4284 Printed in Vietnam ISSUED JUN 04, 2019 - 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Short Bolt Long Bolt (M8 x 45mm) (M8 x 70mm) Lock Washer Flat Washer (8.5 x13mm)
- Page 4 STEP 2 Attach cross bar (B) to legs (C) with bolts (2) and u-washers (5) as shown below. Tighten with Allen key (6). STEP 3 Attach mounting plates (D) to legs (C) with bolts (1), and washers (3) and (4) as shown below. Tighten with Allen key (6).
- Page 5 STEP 3 Attach mounting plates (D) the top (A) with bolts (1), and washers (3) and (4) as shown below. Tighten with Allen key (6). ITEM NO.: T-4284 Printed in Vietnam ISSUED JUN 04, 2019 - 5 -...
