13" X 30" GEARHEAD LATHE w/DRO
The Model SB1049F Lathe is the same machine as the Model SB1049 except for the following:
•
Added a 2-Axis Fagor Digital Readout (DRO).
Except for the differences noted in this insert, all other content in the Model SB1049 Owner's Manual
applies to this machine. Before operating your new lathe, you MUST read and understand this insert,
the entire Model SB1049 Owner's Manual, and the Fagor DRO Owner's Manual to reduce the risk of
injury when using this machine. Keep this insert for later reference.
If you have any further questions about this manual insert or the differences between the Model
SB1049F and the Model SB1049, contact our Technical Support at (360) 734-1540 or email
sales@southbendlathe.com.
New & Changed Parts
REF
PART #
1570
PSB1049F1570
1570-1 PSB1049F1570-1 DRO DISPLAY FAGOR 20-iT
1570-2 PSB1049F1570-2 DRO X-AXIS SCALE FAGOR MKT-102
WARNING: No portion of this manual may be reproduced without written approval.
MODEL SB1049F HEAVY-13
PHONE: (360) 734-1540 •
1570-1
1570-3
1570-2
DESCRIPTION
DRO ASSEMBLY FAGOR 2-AXIS
Copyright © December, 2013 by South Bend Lathe Co.
#TS16215 Printed in Taiwan
Manual Insert
www.southbendlathe.com
1570
REF
PART #
1570-3 PSB1049F1570-3 DRO Y-AXIS SCALE FAGOR MKT-27
1615
PSB1049F1615
1620
PSB1049F1620
1615
1620
SB1049F
DESCRIPTION
MACHINE ID LABEL
MODEL NUMBER BRASS PLATE
V1.12.13
