The Model SB1039F Lathe is the same machine as the Model SB1039 except for the following:
Added a 2-Axis Fagor Digital Readout (DRO).
Except for the differences noted in this insert, all other content in the Model SB1039 Owner's Manual
applies to this machine. Before operating your new lathe, you MUST read and understand this insert,
the entire Model SB1039 Owner's Manual, and the Fagor DRO Owner's Manual to reduce the risk of
injury when using this machine. Keep this insert for later reference.
If you have any further questions about this manual insert or the differences between the Model
SB1039F and the Model SB1039, contact our Technical Support at (360) 734-1639 or email
sales@southbendlathe.com.
New & Changed Parts
REF
PART #
1518
PSB1039F1518
1518-1
PSB1014F2318-1
1518-2 PSB1037F2318-2 DRO X-AXIS SCALE FAGOR MKT-102
WARNING: No portion of this manual may be reproduced without written approval.
MODEL SB1039F
14" X 40" LATHE 220V w/DRO
PHONE: (360) 734-1540 •
1518-1
1518-3
1518-2
DESCRIPTION
DRO ASSEMBLY FAGOR 2-AXIS
DRO DISPLAY FAGOR 20-iT
Copyright © June, 2011 by South Bend Lathe Co.
