- Page 1 MODEL GC430 30" IMPORTANT SAFETY INSTRUCTIONS Carefully read the following important information regarding installation safety and maintenance. Keep these instructions for future reference. MAAN...
-
Page 2: Important Safety Notice
IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE The installation in this manual is intended for qualified installers, service technicians or persons ● with similar qualified background. Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction. - Page 3 IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE WARNING: TO REDUCE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite.
-
Page 4: Parts Supplied
PARTS SUPPLIED: 2 FILTERS... - Page 5 VENTING REQUIREMENTS: HEIGHT & CLEARANCE: • Vent system must terminate to the outside (Roof or side wall). • DO NOT terminate the vent system in an attic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall caps.
-
Page 6: Calculating Vent System Length
IMPORTANT: • ini u round or - rectangular duct (purchased separately) ust be used to aintain a i u airflow efficiency • Always use rigid type etal alu inu ducts if available to a i i e airflow when connecting to provided duct •... -
Page 7: Venting Methods
VENTING METHODS: • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, •... -
Page 8: Electrical Requirements
ELECTRICAL REQUIREMENTS: IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility to contact a qualified electrical installer. If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line. - Page 9 PREPARATIONS: Advanced Preparations: • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. • Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (120-Volt, 60Hz, AC only) and turn on the range hood.
-
Page 10: Installation
INSTALLATION: Installations (refer to Page 4 for parts): NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting the hood on wall studs or lumbars is highly recommended. For consumer safety reasons, mounting screws and anchors have not been supplied with this range l l a l l a anchors. - Page 11 INSTALLATION CONTINUE: Step 5: Installing the damper • Fix the damper on the top vent of hood with 4 screws (requires screw E). • If ventilation system is equipped with an external air duct with a different diameter, apply a reduction fitting. •...
- Page 12 INSTALLATION CONTINUE: Step 7: Installing the decorative chimney and inner chimney bracket • outer chimney. • neys together with the lower chimney bracket, ely. (See Figure # 6) • of the inner chimney bracket on the wall. • Step 8: Installing baffle filters •...
-
Page 13: Control Panel Operation
CONTROL PANEL OPERATION: Control anel a out and uttons Configurations: Electronic Controls with Time ispla ights: ower Settings: Timer function:... -
Page 14: Replacing The Bulbs
REPLACING THE BULBS: Replacing the light bulbs: • This range hood uses halogen bulbs: type G • Make sure the range hood is unplugged or turn OFF breaker • lace a flat-head screwdriver between light cover and housing to re ove cover •... -
Page 15: Mounting Brackets
MOUNTING BRACKETS: Upper/Inner Chimney Bracket 8 1/4” (211 mm) 11 7/8” (302 mm) Lower/Outer Chimney Bracket 11 1/4” (286 mm) 11 7/8” (302 mm) Hood Mounting Bracket Hook 9 1/16” (231 mm) 4 1/2” (115 mm) 4 1/2” (115 mm) 3 1/8”... - Page 16 MEASUREMENTS AND DIAGRAMS: This range hood can reach a 9’ ceiling if installed at 32” from the cooking surface. 10 1/2” 19” to (265 mm) 38 1/4” (480 mm to 970 mm) ” ” 7 mm Glass Depth ” (5 29 /8”...
-
Page 17: Troubleshooting
TROUBLE SHOOTING: 1) If the range hood or halogen light does not • Check if the range hood has been plugged in, operate after installation: make sure that all power has been turned back ON,fused not blown and all electrical wiring are properly connected. -
Page 18: Range Hood Assembly
RANGE HOOD ASSEMBLY:... -
Page 19: Specifications
SPECIFICATIONS: Body design Stainless steel 120V / 60Hz (USA & Canada standard) cULus Certified Power Rating Total input power 250W Motor Input Power 210W Total Ampere 2.2A Levels of speed control 3 levels Radio frequency interference protected Interference Protection Noise Level Single motor Number of Motor Single chamber quiet... -
Page 20: Blower Assembly
BLOWER ASSEMBLY: Description Description Grid Blower Impeller Motor ELECTRICAL ASSEMBLY: Description Description Electrical box base Screw (ST3*6) Electrical cover Capacitor Screw (ST3*10) - Page 21 USE AND CARE INFORMATION: Operations: • Read and understand all instructions and warnings in this anual before operating the appliance Save these instructions for future reference • Always leave safety grills and filters in place Without these co ponents, operating fans could catch on to hair, fingers and loose clothing •...
